Datasensing TFM4/1P-0V Sensors

The Datasensing TFM4/1P-0V Sensors are designed for high precision and reliability, featuring a µTOF HIGH RANGE, SLOW PNP configuration. These sensors are completely filled with resin, ensuring durability and protection against environmental factors. They offer 2 digital outputs (Lon) with a switching frequency ranging from 10 Hz to 80 Hz, making them versatile for various applications. The sensors emit an infrared laser (class 1) with a wide angle, providing a nominal sensing distance of 600mm and a divergent spot dimension of 25°. With a resolution of 3mm and sensitivity adjustment via a trimmer, these sensors are highly adaptable. They feature a hysteresis of ± 6mm and operate on the Time of Flight principle. The output type is 2 x PNP LO, with an output function of LO, and a switching frequency of ? 10Hz. The response time is a swift 50ms, and they operate within a voltage range of 19.2 to 28.8VDC. The sensors are equipped with LED indicators for easy status monitoring: green for run, red for out of the operating range, and yellow for status. They are protected against short-circuits, reverse polarity, and impulsive overvoltage, ensuring reliable performance. The housing is made of PA66 + ABS, with an active head material of glass, and they are designed to withstand operating temperatures from -10°C to +50°C. With IP67 protection, these sensors are completely protected against electrical damages and are suitable for use in humid environments with less than 80% humidity (without condensation). They are CE approved and EMC compatible with EN 60947-5-2 standards, making them a robust choice for industrial applications. The compact dimensions of 13 x 2 x 31.2mm and a cubic diameter/dimension make them easy to integrate into various systems.
