Datasensing UK1D/G2-0ESY Sensors

The Datasensing UK1D/G2-0ESY Sensors are designed for precision and reliability, featuring an M18 analog 4-20mA output with a convenient M12 connection. These sensors offer versatile models with digital programmable outputs and current or voltage analogue outputs, making them suitable for a wide range of applications. The adjustable hysteresis function, along with programmable double digital outputs, is specifically tailored for level detection. With a working area that can be adjusted using the Teach-in button, these sensors ensure a quick setup and operation. The multifunction LED indicator provides clear feedback on output type, adjustment procedures, NO/NC selection, and reverse analog output slope. Key specifications include a nominal sensing distance of 1600mm, a thermal drift of ±2%, and a repeat accuracy of 0.50%. The sensors boast a beam angle of 15° ± 2°, a resolution of ?3mm, and a sensitivity adjustment via the Teach-in button. They are equipped with thermal compensation, a minimum sensing distance of 150mm, and a linearity error of 1%. Operating on a voltage range of 10 - 30Vdc, these sensors have a no-load supply current of ?50mA and a load current of 100mA. They feature short-circuit, reverse polarity, and impulsive overvoltage protection, ensuring durability and safety. The robust PBT housing, IP67 mechanical protection, and compliance with CE cULus and IEC standards make these sensors ideal for challenging environments. Supplied with two M18x1 nuts and two Ø 18 washers, the Datasensing UK1D/G2-0ESY Sensors are ready for immediate installation and use.
