Dynapar 112859-0020 20 ft 5-Pin M12 Cable Assembly
Dynapar
$165.00
Dynapar 112859-0020 M12 A-Coded 5-Pin Cordset
The Dynapar 112859-0020 is a molded M12 cordset with an A-coded 5-pin connection, 20 ft cable. Molded cordsets are factory-terminated and sealed, so they install quickly and hold their rating in washdown, oil, and vibration where hand-wired terminations tend to fail.
A-coded M12 is the standard interface for sensors, actuators, valves, and I/O modules, and is also used for DeviceNet, CANopen, and IO-Link connections.
Specifications
| Brand | Dynapar |
| Part Number | 112859-0020 |
| Product Type | Cordset |
| Connector | M12 |
| Coding | A-Coded |
| Number of Pins | 5 |
| Cable Length | 20 ft |
| Shielded | Yes |
Need help matching coding, pin count, or length to your device? Contact Automation Distribution and our team will help you choose the right M12 connection.
- Length ( Range ):
- 20 feet
- Temperature ( Wire Only ):
- +105C
- Connector Type 1 ( Encoder Side ):
- M12 (A-Coded)
- Connector Type 2 ( Non-Encoder Side ):
- Leads
- Connector Pin Count:
- 5
- Leads ( Not Including Shield ):
- 5
- Wire Gauge:
- 22AWG
