Dynapar G0557397 Encoder, 5000 PPR, Hollow Shaft, 5 VDC, Line Driver Output

Dynapar
SKU:
G0557397
Availability:
Factory stock
$2,316.60
Condition:
New
Current Stock:
Description
The Dynapar G0557397 is a compact hollowshaft incremental optical encoder designed for high-resolution position and speed feedback in industrial applications. It supports resolutions up to 5000 PPR with options for 500, 512, 1000, 1024, 2000, 2048, 2500, 4096, or 5000 PPR, powered by 5 VDC ±10% at 150-175 mA max, and offers output signals including line driver (40 mA sink/source) or open collector configurations. Mechanical features include a 1.96" outer diameter, brass hub diameters from 1/4" to 6 mm, spring tether mounting with ±15° misalignment tolerance, 100G shock resistance, 2.5G vibration (5-2000 Hz), and operation from -40°C to +120°C in an IP40/NEMA 1 enclosure. Documentation - Technical Datasheet: https://www.dynapar.com/products_and_solutions/encoders/hollowshaft/g0557397-datasheet.pdf - Installation Instructions: https://www.dynapar.com/support/product-manuals/g0557397-installation-guide.pdf - Product Specifications: https://www.dynapar.com/products_and_solutions/product_quicklinks/g0557397 - CAD Drawings: https://www.dynapar.com/products_and_solutions/encoders/cad-models/g0557397.zip
