Fibox UL PC 233009 PC Enclosure - Gray Cover
Fibox
$192.75
Product card: UL PC 233009 Including: Base with screws for mounting plate/DIN-rail, cover with PUR gasket and stainless steel cover screws. Product nbr: 7042870 Description: UL Enclosure, PC Remarks: Grey cover Package: 9 Unit: PCS Product group: EURONORD UL PC Enclosures EAN: 6418074054401 Electric No. Denmark: 8212032143 Electric No. Italy: 7301060U ETIM: EC000261 EC000261 Support items: Product card (PDF) Dimensional drawing (mm) Dimensional drawing (inch) Cad-files (registration needed) Dimensions: Length (mm): 230.0 Width (mm): 300.0 Height (mm): 87.0 Length (inch): 9.1 Width (inch): 11.8 Height (inch): 3.4 Categories: UL-enclosures Materials: Material: Polycarbonate Base colour: RAL 7035 -light grey Cover screws material: Stainless steel Cover colour: RAL 7035 -light grey Gasket material: Polyurethane Temperatures: Temperature ??C (short term): -40 ? 120 ??C Temperature ??C (continuous): -40 ? 80 ??C Temperature ??F (short term): -40 ? 250 ??F Temperature ??F (continuous): -40 ? 175 ??F Ratings: Ingress Protection (EN 60529): IP66/IP67 Impact Resistance (EN 62262): IK07/IK08 Electrical insulation: Totally insulated Halogen free (DIN/VDE 0472, Part 815): 1 UV resistance: UL 508 Flammability Rating: UL 746C 5" UL Type: Glow Wire Test (IEC 695-2-1) ??C: 960 Certficates: Underwriters Laboratories SGS Fimko UL Canada Gost R Product is connected to following catalogs: Fibox Enclosures : UL ENCLOSURES : UL EURONORD PC
- Dimensions (in):
- 9.06 x 11.81 x 3.54
- Dimensions (mm):
- 230 x 300 x 90
- Size Group:
- PC 2330
- Transparency:
- Opaque
- Datasheet:
- View
