Horner Automation HE-X10R-441 X10 Controller 10", 12 DC In, 2 DC Out, 6 Relay Out, 4 Analog In (mA/RTD), 2 Analog Out (mA), WebMI License unlimited
Horner Automation
$1,394.00
X10 Controller 10", 12 Dc In, 2 Dc Out, 6 Relay Out, 4 Analog In (Ma/Rtd), 2 Analog Out (Ma), Webmi License Unlimited Preloaded
- Series:
- X10 (Micro OCS)
- Product Type:
- All-in-One PLC/HMI Controller
- DC In:
- 12
- DC Out:
- 2
- Relays:
- 6
- HS In:
- 4
- HS Out:
- 2
- Analog In:
- 4 (4-20mA)
- RTD Support:
- PT-100 (-50 to 200C)
- Analog Out:
- 2 (4-20mA)
- Output Type:
- Sinking with integral pull-up
- Ladder Logic Memory:
- 256 kB
- Logic Scan Rate:
- 0.4 mS/K
- Removable Memory:
- microSD
- Display:
- 10.1 LCD with LED, 300 nits"
- Resolution:
- 1024 x 600
- Ethernet Ports:
- 1 (10/100)
- Serial Ports:
- 1 RS-232 & 1 RS-485
- USB:
- Mini-B
- CAN Networks:
- 1 (CsCAN), 1,640 ft max
- Digital I/O Max:
- 1024 / 1024
- Analog I/O Max:
- 256 / 256
- GP Registers:
- 5000 retentive
- Height:
- 6.5 / 166.20 mm"
- Width:
- 10.4 / 263.9 mm"
- Depth:
- 2.2 / 55.8 mm"
- Input Voltage:
- 10-30 VDC
- Operating Temperature:
- -10 to 60C
- Humidity (non-condensing):
- 5 to 95%
- Product Certifications:
- CE, cULus
- Environmental Rating:
- UL 50E Type 1, 4x (indoor), 12, 12k, 13
- Special Order Option:
- WebMI Unlimited license pre-loaded
- Datasheet:
- View
