Leuze KDS U-M12-4A-M12-4W-V1-030 M12 A-Coded 4-Pin Male to Female Double-Ended Cordset, 3 m, PVC
Leuze
$29.00
Leuze KDS U-M12-4A-M12-4W-V1-030 M12 A-Coded 4-Pin Double-Ended Cordset
The Leuze KDS U-M12-4A-M12-4W-V1-030 is a molded M12 cordset with an A-coded 4-pin connection, straight orientation, 3 m cable and PVC jacket. Molded cordsets are factory-terminated and sealed, so they install quickly and hold their rating in washdown, oil, and vibration where hand-wired terminations tend to fail.
A-coded M12 is the standard interface for sensors, actuators, valves, and I/O modules, and is also used for DeviceNet, CANopen, and IO-Link connections.
Specifications
| Brand | Leuze |
| Part Number | KDS U-M12-4A-M12-4W-V1-030 |
| Manufacturer ID | 50130754 |
| Product Type | Double-ended cordset |
| Connector | M12 |
| Coding | A-Coded |
| Number of Pins | 4 |
| Gender | Male / Female |
| Orientation | Straight |
| Cable Length | 3 m |
| Jacket Material | PVC |
Need help matching coding, pin count, or length to your device? Contact Automation Distribution and our team will help you choose the right M12 connection.
- Application:
- Chemical resistant
- Type:
- Female
- Version:
- Axial
- Connector, LED:
- No
- Type:
- Male
- Version:
- Angled
- Sheathing color:
- Black
- Shielded:
- No
- Silicone-free:
- Yes
- Cable design:
- Interconnection cable
- Cable length:
- 3,000 mm
- Sheathing material:
- PVC
- Wire insulation:
- PVC
- Suitability for drag chains:
- No
- Properties of the outer sheathing:
- Free of CFC, cadmium, silicone and lead, easily machine-processable
- Resistance of the outer sheathing:
- Good oil, gasoline and chemical resistance, flame retardant in accordance with UL 1581 VW1 / CSA FT1
- Width across flats:
- 13 mm
- Net weight:
- 144 g
- Bending radius, flexible laying, min.:
- Min. 10 x cable diameter
- Bending radius, stationary laying, min.:
- Min. 5 x cable diameter
- Degree of protection:
- IP 65,IP 67
- Approvals:
- c UL US
- UL file number:
- E366145
- Customs tariff number:
- 85444290
- ECLASS 5.1.4:
- 27279201
- ECLASS 8.0:
- 27279218
- ECLASS 9.0:
- 27060311
- ECLASS 10.0:
- 27060311
- ECLASS 11.0:
- 27060311
- ECLASS 12.0:
- 27060311
- ECLASS 13.0:
- 27060311
- ECLASS 14.0:
- 27060311
- ECLASS 15.0:
- 27060311
- ETIM 5.0:
- EC001855
- ETIM 6.0:
- EC001855
- ETIM 7.0:
- EC001855
- ETIM 8.0:
- EC001855
- ETIM 9.0:
- EC001855
- ETIM 10.0:
- EC001855
- Datasheet:
- View
- Brochure:
- View
- Declaration of Conformity:
- View
- Coding:
- A-Coded
- Pins:
- 4
- Cordset Design:
- Double-Ended
