Leuze A7-MP2-400 Tower light element
Leuze
$53.00
The Leuze A7-MP2-400 is a cylindrical tower light element (Ø 70 mm x 500 mm) designed for base mounting in the A7 series signaling systems, featuring a single-sided module holder and one end cap for modular stack assembly. It uses tension spring terminal connections for secure wiring, plastic (PC-ABS) housing, and supports horizontal or vertical screw fastening with 180° adjustability in 15° increments. Rated for -10 to 60 °C operation and IP66 protection (when mounted on compatible housing), it holds CE and CSA approvals, suitable for industrial machine status indication and assembly line signaling.
Documentation
- Technical Datasheet: https://www.leuze.com/en-us/a7-mp2-400/50142454
- Product Overview (Mounting Systems): https://www.leuze.com/en-us/products/accessories/optical-and-acoustic-signalers/individually-configurable-tower-lights/mounting-systems
- Operating Instructions: https://www.leuze.com/en-us/downloads/a7-mp2-400-operating-instructions
- CAD Data: https://www.leuze.com/en-us/cad/a7-mp2-400
- Series:
- A7
- Type of connection:
- Terminal
- Type of terminal:
- Tension spring technology
- Design:
- Cylindrical
- Dimension (Ø x L):
- 70 mm x 500 mm
- Housing material:
- Plastic
- Net weight:
- 227 g
- Housing color:
- Black,Gray
- Design of mounting device:
- Base mounting
- Type of fastening, at system:
- Screw type / horizontal,Screw type / vertical
- Type of mounting device:
- 180°, adjustable in intervals of 15°
- Module holder:
- One side
- Number of end caps:
- 1 Piece(s)
- Ambient temperature, operation:
- -10 ... 60 °C
- Degree of protection:
- IP 66, Only when mounted on a housing with the same degree of protection
- Approvals:
- CE,CSA
- Customs tariff number:
- 85318070
- ECLASS 5.1.4:
- 27371234
- ECLASS 8.0:
- 27371234
- ECLASS 9.0:
- 27371234
- ECLASS 10.0:
- 27371234
- ECLASS 11.0:
- 27371234
- ECLASS 12.0:
- 27371234
- ECLASS 13.0:
- 27371234
- ECLASS 14.0:
- 27371234
- ECLASS 15.0:
- 27371234
- ETIM 5.0:
- EC001259
- ETIM 6.0:
- EC001259
- ETIM 7.0:
- EC001259
- ETIM 8.0:
- EC001259
- ETIM 9.0:
- EC001259
- ETIM 10.0:
- EC001259
- Datasheet:
- View
- Declaration of Conformity:
- View
