Leuze PRK25CL1/XX-M12 Industrial Sensor System
Leuze
$234.00
The PRK25CL1/XX-M12 is a precision industrial sensor engineered for demanding automation applications. Featuring IP67 protection and wide operating temperature range, it delivers reliable performance in manufacturing, logistics, and process control environments.
Technical Specifications:
Light source: LASER, red emission
Protection rating: IP67 (dust-tight, water-resistant for washdown environments)
Supply voltage: 10...30 V DC with reverse polarity protection
Operating temperature: -40...60 °C (extended cold storage rating)
Connection: M12 quick-disconnect connector
Technical Documentation:
Complete technical specifications, dimensional drawings, wiring diagrams, and safety documentation are available on the Leuze website at https://www.leuze.com/en-us/usa/products (search model PRK25CL1/XX-M12). CAD models in STEP and EPLAN formats available for download to streamline machine design and panel layout.
- Series:
- 25C
- Suitable for:
- 25C series sensors
- Light source:
- Laser, Red
- Laser class:
- 1, IEC/EN 60825-1:2007
- Light spot size [at sensor distance]:
- 3 mm x 5 mm [1,000 mm]
- Type of light spot geometry:
- elliptic
- Supply voltage UB:
- 10 ... 30 V, DC, Incl. residual ripple
- Residual ripple:
- 0 ... 15 %, From UB
- Type of connection:
- Connector
- Thread size:
- M12
- Type:
- Male
- No. of pins:
- 4 -pin
- Encoding:
- A-coded
- Dimension (W x H x L):
- 15 mm x 42.7 mm x 30 mm
- Housing material:
- Metal,Plastic
- Plastic housing:
- ABS
- Lens cover material:
- Plastic
- Net weight:
- 22 g
- Housing color:
- Red
- Type of fastening:
- Through-hole mounting with M4 thread,Via optional mounting device
- Compatibility of materials:
- ECOLAB
- Ambient temperature, operation:
- -40 ... 60 °C
- Ambient temperature, storage:
- -40 ... 70 °C
- Degree of protection:
- IP 67,IP 69K
- Protection class:
- III
- Customs tariff number:
- 85365019
- ECLASS 5.1.4:
- 27279210
- ECLASS 8.0:
- 27279210
- ECLASS 9.0:
- 27273607
- ECLASS 10.0:
- 27273607
- ECLASS 11.0:
- 27273607
- ECLASS 12.0:
- 27273607
- ECLASS 13.0:
- 27273607
- ECLASS 14.0:
- 27273607
- ECLASS 15.0:
- 27273607
- ETIM 5.0:
- EC002498
- ETIM 6.0:
- EC003015
- ETIM 7.0:
- EC003015
- ETIM 8.0:
- EC003015
- ETIM 9.0:
- EC003015
- ETIM 10.0:
- EC003015
- Datasheet:
- View
- Declaration of Conformity:
- View
