Lutze 111488 su plus (c) pur ul feedback
LutzeTechnical Data
Construction
Description
SUPERFLEX???? PLUS (C) PUR FEEDBACK
Number of conductors/cross-section
(5?????2?????AWG22)
Jacket material
PUR
Jacket color
green RAL 6018
Outer ??
9,2 mm
Outer ??
0,362 inch
Surface
- adhesion-free
- matt
Weight
10,7 kg/100 m
Weight
121 Lbs/Mft
Cu-Index
5,4 kg/100 m
Cu-Index
81 Lbs/Mft
Element 1
Element construction
(5?????2?????AWG22)
Conductor
CU-wire bare
Conductor category
- IEC 60228, Class 6
- Superfinely stranded DIN VDE 0295
- class 6
Conductor marking
- black/white
- black
- red/white
- red
- green/white
- green
- grey/white
- grey
- orange/white
- orange
Conductor insulation
Special TPE
overall construction
Overall stranding
- stranded pairs
- layer pitch optimised
- conductors twisted without mechanical stress
Overall wrapping
Fleece taping
Overall shield
- Braid shield
- Tinned copper wires
- optical cover approx. 85%
Jacket characteristics
- Flame-retardant
- Oil resistant
- grease-resistant
- petrol-resistant (alcohol-free)
- kerosene-resistant
- Silicone-free
- Halogen free
Technical data
Rated voltage
1000 V
Test voltage type
AC2000V
Temperature range moving
-25 ?????C ??????? +80 ?????C
Temperature range fixed
-40 ?????C ??????? +80 ?????C
Minimum bending radius moving
10?????D
Minimum bending radius fixed
6?????D
Element 1
Element construction
(5?????2?????AWG22)
Insulation resistance at 20 ?????C
200 M?????????km
Approvals/Standards
Approvals
cURus
UL style
AWM 21223
Conformity
- CE
- RoHS
- REACH
Burning behavior according to
- IEC 60332-1
- DIN EN 60332-1-2
- VDE 0482 322-1-2
- UL 1581 Part 1080 VW-1
- UL FT1
Halogen free according to
- DIN EN 60754-1
- IEC 60754-1
General
Note
CE These products are in conformity with the EU Low Voltage Directive 2014/35/EU
Incremental encoder cable, connection cable for tacho sensor, brake sensor, speed sensor Due to optimized cable construction optimally suited for continuous flexing applications in C-tracks Very good resitance against aggressive coolants and lubricants Especially for industrial environments in mechanical and system engineering
