Description
Technical Data
Technical data
Rated voltage UN
AC24V
Rated voltage max.
50 V
Rated current
1,5
Pole number
8
Transfer rate
10 Gbit/s
Category
Cat.6A
Contact type
1 : 1
Shielding
connected through
General
Form male 1
RJ45
Degree of polution
3
Insulation resistance
> 100 M?
Contact resistance
< 30 m?
Flamability according to UL 94
V0
Protection class
IP65 in closed and IP20 in inserted condition
Housing material
- PA
- PBT
Cover
TPU
Contact material
CuSn, gold-plated
Mounting
Front installation
Installation depth
70 mm
Number of conductors/cross-section
8??2
Operation temperature range
-20???C??70???C
Storage temperature range
-20???C??80???C
Temperature range connector
-20???C??70???C
Dimensions (????d)
30 ?? 30 mm
Mechanical service life
>750 insertion cycles
Weight
0,024 kg/piece
PU
1 piece
Dimensions
Circuit diagram
Mounting diagram
Pin layout
Accessories
- Included in the delivery:
- captive safety cap
