Lutze 722767 dra18-12

Lutze 722767 dra18-12

Lutze
SKU:
722767
Availability:
Contact us to confirm availability and lead times.
$38.39
Condition:
New
Current Stock:
Description

Technical Data

Input

Number of phases
1
Rated voltage UN
AC 100????240 V
Operation voltage range
AC 90????265 V / DC 120????370 V
Line frequency
47????63 Hz
Rated current IN
200 mA @ AC 115 V / 110 mA @ AC 230 V
Inrush current
10 A @ AC 115 V / 18 A @ AC 230 V
Internal fuse
2 A Typ-T AC 250 V
External fuse
Mini-circuit breaker: B 4 A

Output

Rated voltage UN
DC12V
Rated current IN
1,5 A
Heat dissipation
4.65 W @ AC 230 V
Setting range Uout min./Uout max.
10.8-13.8 V
Accuracy
??ñ1 %
Load regulation
??ñ2 %
Line regulation
??ñ1 %
Rise time
1 s
Temperature coefficient
??ñ0.03 % / ???C
Ripple and Noise
<50 mV
Hold up time
20 ms @ 115 V / 75 ms @ 230 V
Status indication DC ON LED green
????10.8 V
Status indication DC LOW LED red
<9????10.8 V
Parallel / redundant mode
max. 2 devices / via external decoupling diodes
Efficiency
77 %
Over voltage protection
125????145 %
Rated over load protection
110????135 %
Short circuit
Hiccup Mode

Monitoring

DC ON Control (Rdy)
LED green/red

General

Switching frequency
approx. 100 kHz
Insulation voltage input / output
AC 3.0 kVeff
Insulation voltage input / ground
AC 1.5 kVeff
Insulation resistance at DC 500 V
100 M?
Derating
Capacity: -3 %/???C starting at +60 ???C
Operation temperature range
-20 ???C ???? +70 ???C (Derating)
Storage temperature range
-25???C????85???C
MTBF
797000 h
Relative air humidity
20 ???? 95 % RH, not condensing
Cooling
Air convection, 25 mm clearance all-round
Housing material
Plastic
Mounting
  • DIN rail mountable TS35
  • (EN 60715)
Application height
2000 m
Installation position
vertical
Protection class
IP20
Protection class
II (SELV, PELV)
Over voltage category
II
Degree of polution
2
Weight
0,15 kg/piece
Connection type
  • Spring terminal
  • 0.20 mm2 ???? 2.0 mm2
Dimensions (w ????? h ????? d)
22,5?????90?????115 mm
Approvals
  • UL 508 listed
  • UL 60950-1
  • UL 1310 Class 2
  • EN 60950-1
  • EN 50081-1
  • EN 55022 Class B
  • EN 61000-3-2
  • EN 61000-3-3
  • EN 50082-1
  • EN 55024 Class I
  • Division 2, Groups A, B, C, D
PU
1 piece
Dimensions
PIN assignment
Derating
Redundant operation
Short circuit characteristics
