Nexen 966844 Premium Roller Pinion Rack

Nexen
SKU:
966844
Availability:
Contact us to confirm availability and lead times.
$1,451.00
Condition:
New
Current Stock:
Description

Premium Roller Pinion Rack



RPS12R-B0048P2U,SPCL

Premium Grade, High Precision, Zero Backlash, Corrosion Resistant, Lube Free Operation Possible

Configuration Notes: Special 48 mm Rack Section Consult Nexen Before Using Total System Performance Will Be The Lesser Of The Pinion And Rack Or Gear Combination See Pinion Options Under Accessories

Length=48 mm

Product Features=Premium Grade, High Precision, Zero Backlash, Corrosion Resistant, Lube Free Operation Possible; Restrictions=Cut Ends Must Be At The End Of The Run, Pinion Must Not Cross Cut Points
Additional Information
Weight:
0.4 lbs
Primary Finish:
Dense Hard Chrome
Min Ambient Temperature:
-5 °C
Max Ambient Temperature:
40 °C
CE Certified:
CE
RoHS Compliant:
RoHS
Product Weight:
0.06 kg
Max Acceleration Thrust:
500 N
Max Average Thrust:
500 N
Max Static Linear Force:
750 N
Positional Accuracy:
± 30 µm
Linear Repeatability:
± 5 µm
Approximate Life:
More Than 30000000, Roller Contacts Per Tooth At Rated Accuracy And Max Life Ratings
Materials Of Construction:
Black Thin Dense Hard Chrome On Steel
Max Linear Speed:
8 m/s
RPS Size:
12
RPS Width:
B-Width, Only Compatible with B-Width Roller Pinions
Backlash Rating:
Zero Backlash
