Schneider Electric BDF36050 Molded Case Circuit Brkr 600Y/347V 50A

(No reviews yet) Write a Review

Write a Review

Schneider Electric BDF36050 Molded Case Circuit Brkr 600Y/347V 50A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

BDF36050

UPC:

3606481149275

MPN:

Condition:

New

Connection Pitch:

27 mm

Ip Degree Of Protection:

front cover IP40 IEC 60529

Sustainable Offer Status:

Green Premium product

Operating Altitude:

6561.68 ft (2000 m) without derating || 5000 m with derating

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

Depth:

80 mm

Product Or Component Type:

circuit breaker

Device Short Name:

BD 050

Protected Poles Description:

3t

Device Application:

distribution

Utilisation Category:

category A

Height:

137 mm

Quality Labels:

CE

Environmental Disclosure:

ENVPEP1610005EN

Control Type:

toggle

Ambient Air Temperature For Storage:

-50-85 °C

Electrical Durability:

10000 cycles IEC 947-1 Annex K ed 5.2 440 V In

Number Of Slots:

1 auxiliary switch OF plug-in) || 1 voltage release MN or MX plug-in) || 1 alarm switch SD plug-in)

Color:

Gray RAL 7016)

Product Certifications:

UL || IEC || CCC || EAC || CSA || NOM

Halogen Content Performance:

Halogen free product

[Ui] Rated Insulation Voltage:

800 V IEC 60947-2

[Ue] Rated Operational Voltage:

525 V AC 50/60 Hz UL 489

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Width:

81 mm

Mounting Mode:

clip-on 35 mm symmetrical DIN rail) || by screws plate)

Tightening Torque:

5-5 N.m 2.5-16 mm² (AWG 14...AWG 4) || 9-9 N.m 25-95 mm² (AWG 3...AWG 3/0)

Rohs Exemption Information:

Yes

Continuous Current Rating:

0.8

Pollution Degree:

3 IEC 60947-1

Standards:

GB 14048.2 || EN/IEC 60947-2 || UL 489 || CSA C22.2 No 5 || EN/IEC 60947-5-1 || NEMA AB1 || NMX J-266

[Ics] Rated Service Breaking Capacity:

25 kA 220...240 V AC 50/60 Hz IEC 60947-2 || 14 kA 500...525 V AC 50/60 Hz IEC 60947-2 || 18 kA 380...415 V AC 50/60 Hz IEC 60947-2 || 18 kA 440 V AC 50/60 Hz IEC 60947-2

Range:

PowerPact

Suitability For Isolation:

yes IEC 60947-2

Trip Unit Technology:

thermal-magneticTM-D,

Trip Unit Name:

TM-D

Mercury Free:

Yes

California Proposition 65:

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information

Product Name:

PowerPact B

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Ambient Air Temperature For Operation:

-25-70 °C

Eu Rohs Directive:

Compliant with Exemptions

Circuit Breaker Application:

HACR rated

Breaking Capacity Code:

D

Local Signalling:

presence of auxiliary contacts flag green)

Quantity Per Set:

set of 1

Network Frequency:

50/60 Hz

Pvc Free:

Yes

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Breaking Capacity:

25 kA 208Y/120 V AC 50/60 Hz UL 489 || 18 kA 240 V AC 50/60 Hz UL 489 || Icu 25 kA 480/277 V AC 50/60 Hz UL 489 || Icu 14 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600Y/347 V AC 50/60 Hz UL 489 || 14 kA 250 V DC UL 489 || 25 kA || Icu 18 kA

Circularity Profile:

N/A

Electrical Connection:

terminal nut, ON and OFF end

Mechanical Durability:

15000 cycles IEC 947-1 Annex K ed 5.2

Net Weight:

0.924 kg

Awg Gauge:

AWG 14...AWG 8 aluminium/copper || AWG 6...AWG 3/0 aluminium/copper

Ik Degree Of Protection:

IK07 IEC 62262

Poles Description:

3P

Line Rated Current:

50-50 A

Wire Stripping Length:

20 mm

9 Mm Pitches:

9
