Schneider Electric EDB26100 Miniature Circuit Breaker 600V 100A

(No reviews yet) Write a Review
SKU:
EDB26100
UPC:
785901412335
Condition:
New
Breaking Capacity Code:
D
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
[Ue] Rated Operational Voltage:
600Y/347 V AC
Line Rated Current:
100 A
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Width:
1.96 in
Rohs Exemption Information:
Yes
Device Short Name:
EDB
Ambient Air Temperature For Operation:
40 °C
Number Of Spaces Required:
2
Number Of Poles:
2
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Module Type:
E-Frame
Circuit Breaker Application:
HACR rated
Tightening Torque:
3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10) || 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
Breaking Capacity:
14 kA 600Y/347 V AC
Number Of Spaces:
2
Holding Current:
1000 A
Mercury Free:
Yes
Trip Unit Rating:
2300-2300 A
Product Certifications:
cULus
Range Of Product:
125 A Frame EDB-EGB-EJB
Local Signalling:
trip indicator
Depth:
4.05 in
Trip Unit Technology:
thermal-magnetic
Height:
5.66 in
Product Or Component Type:
miniature circuit-breaker
Product Destination:
NF panelboard
Net Weight:
3 lb(US)
Warranty:
18 months
Mounting Mode:
bolt-on
Awg Gauge:
AWG 12...AWG 2/0 aluminium || AWG 14...AWG 2/0 copper
Electrical Connection:
lugs aluminium
Protection Type:
short-circuit || overload
$756.00

Description

E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 100A, 2 pole, and has an operating voltage of 600Y/347 VAC. It also provides a 25 kA max interrupt rating at 120 VAC. This device has a hold current of 1000A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 2300A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This breaker was calibrated for 40 degrees C. HACR rated.
