Schneider Electric EJB24020SA Miniature Circuit Breaker 480Y/277V 20A

(No reviews yet) Write a Review
SKU:
EJB24020SA
UPC:
3606486143780
Condition:
New
Trip Unit Technology:
thermal-magnetic
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Tightening Torque:
3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)
Net Weight:
3 lb(US)
Breaking Capacity:
65 kA 277 V AC || 100 kA 240 V AC || 65 kA 480Y/277 V AC || 100 kA 120 V AC || 100 kA 120/240 V AC
Ambient Air Temperature For Operation:
40 °C
Local Signalling:
trip indicator
Device Short Name:
EJB
Circuit Breaker Application:
HACR rated || HID rated
Awg Gauge:
AWG 12...AWG 6 aluminium || AWG 14...AWG 6 copper
Electrical Connection:
lugs aluminium
Warranty:
18 months
Trip Unit Rating:
875-875 A
[Ue] Rated Operational Voltage:
480Y/277 V AC
Holding Current:
270 A
Product Certifications:
cULus
Device Composition:
shunt trip
Line Rated Current:
20 A
Depth:
4.05 in
Product Destination:
NF panelboard
Number Of Poles:
2
Width:
2.94 in
Height:
5.66 in
Mounting Mode:
bolt-on
Eu Rohs Directive:
Compliant with Exemptions
Module Type:
E-Frame
Mercury Free:
Yes
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Product Or Component Type:
miniature circuit-breaker
Rohs Exemption Information:
Yes
Number Of Spaces:
3
Protection Type:
overload || short-circuit
Breaking Capacity Code:
J
Range Of Product:
125 A Frame EDB-EGB-EJB
Number Of Spaces Required:
3
Catalog:
View
Datasheet:
View
$1,996.00

Description

E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer superior overload and short circuit protection. All E-Frame breakers have a thermal-magnetic trip unit as well as signal indicator that will indicate when a trip has occur. Mounting bolts are used to hold these breakers in place. This E-Frame breaker is 20A, 2 pole, and has an operating voltage of 480Y/277 VAC. It also provides a 100 kA max interrupt rating at 120 VAC. This device has a hold current of 270A which is the maximum current the breaker can be held to ensure it will trip and a trip current of 875A which is the current value when the breaker is guaranteed to trip. Many accessories are available for this breaker. This one includes a shunt trip. This breaker was calibrated for 40 degrees C. This product is UL Listed as High Intensity Discharge. HACR rated.
