Schneider Electric EJB34030CA Miniature Circuit Breaker 480Y/277V 30A

(No reviews yet) Write a Review

Write a Review

Schneider Electric EJB34030CA Miniature Circuit Breaker 480Y/277V 30A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

EJB34030CA

UPC:

3606486143094

MPN:

Condition:

New

Height:

5.66 in

Trip Unit Technology:

thermal-magnetic

Tightening Torque:

3.4-3.4 N.m 2.5-16 mm² (AWG 14...AWG 6)

Line Rated Current:

30 A

Mounting Mode:

bolt-on

Depth:

4.05 in

Width:

2.94 in

Awg Gauge:

AWG 12...AWG 6 aluminium || AWG 14...AWG 6 copper

Ambient Air Temperature For Operation:

50 °C

Electrical Connection:

lugs aluminium

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Rohs Exemption Information:

Yes

Net Weight:

4 lb(US)

Protection Type:

short-circuit || overload

Product Or Component Type:

miniature circuit-breaker

Product Destination:

NF panelboard

Trip Unit Rating:

875-875 A

[Ue] Rated Operational Voltage:

480Y/277 V AC

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Circuit Breaker Application:

HID rated || HACR rated

Breaking Capacity:

65 kA 277 V AC || 100 kA 240 V AC || 65 kA 480Y/277 V AC || 100 kA 120 V AC || 100 kA 120/240 V AC

Number Of Spaces:

3

Mercury Free:

Yes

Module Type:

E-Frame

Number Of Spaces Required:

3

Breaking Capacity Code:

J

Number Of Poles:

3

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Holding Current:

270 A

Product Certifications:

cULus

Device Short Name:

EJB

Range Of Product:

125 A Frame EDB-EGB-EJB

Local Signalling:

trip indicator
