Schneider Electric HDP36150 Molded Case Circuit Breaker 600V 150A

(No reviews yet) Write a Review

Write a Review

Schneider Electric HDP36150 Molded Case Circuit Breaker 600V 150A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

HDP36150

UPC:

785901854258

MPN:

Condition:

New

Color:

Black

Eu Rohs Directive:

Compliant with Exemptions

Control Type:

toggle

Product Or Component Type:

circuit breaker

Continuous Current Rating:

0.8

Network Frequency:

50/60 Hz

Magnetic Hold Current:

900 A

Ambient Air Temperature For Storage:

-50-85 °C

Rohs Exemption Information:

Yes

Range:

PowerPact

Mounting Support:

lug

Mercury Free:

Yes

Poles Description:

3P

Magnetic Tripping Current:

1700-1700 A

Device Application:

distribution

Product Certifications:

UL || CSA || NOM

Breaking Capacity Code:

D

Width:

104 mm

Sustainable Offer Status:

Green Premium product

Wire Stripping Length:

16 mm

Trip Unit Technology:

thermal-magnetic

Height:

163 mm

Standards:

UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

[Ics] Rated Service Breaking Capacity:

25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2

Warranty:

18 months

Suitability For Isolation:

yes IEC 60947-2

Breaking Capacity:

25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC

Ip Degree Of Protection:

front cover IP40 IEC 60529

Pvc Free:

Yes

Tightening Torque:

5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)

Communication Interface:

Modbus || Ethernet

Circuit Breaker Application:

HACR rated

Local Signalling:

switched off (OFF) 1 trip indicator green)

Protected Poles Description:

3t

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Ambient Air Temperature For Operation:

-2-70 °C

Quality Labels:

CE

Quantity Per Set:

1

Product Name:

PowerPact H

Circularity Profile:

ENVEOLI2206027EN

Environmental Disclosure:

ENVPEP2206027EN

Awg Gauge:

AWG 14...AWG 3/0 aluminium/copper terminal

[Ui] Rated Insulation Voltage:

750 V IEC 60947-2

Electrical Connection:

terminal nut, line || lugs, load

Terminal Identifier:

AL150HD

Mounting Mode:

unit mount lug)

Depth:

86 mm

Utilisation Category:

category A

California Proposition 65:

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information

Number Of Slots:

2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)

Operating Altitude:

< 6561.68 ft (2000 m) without derating || 5000 m with derating

[Ue] Rated Operational Voltage:

690 V AC 50/60 Hz IEC 60947-3

Net Weight:

2.2 kg

Pollution Degree:

3 IEC 60947-1

Line Rated Current:

150-150 A
