Schneider Electric HGP36070 Molded Case Circuit Breaker 600V 70A
Schneider Electric
$1,701.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 18kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has terminal nuts on the line side and lugs on the load side. This PowerPacT H, 70A, 3 pole, circuit breaker has a breaking capacity of 18kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Range:
- PowerPact
- Product Or Component Type:
- circuit breaker
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- Color:
- Black
- Control Type:
- toggle
- Mounting Mode:
- unit mount lug)
- Electrical Connection:
- terminal nut, line || lugs, load
- Mercury Free:
- Yes
- Mounting Support:
- lug
- Breaking Capacity:
- 65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Pvc Free:
- Yes
- Poles Description:
- 3P
- Warranty:
- 18 months
- Communication Interface:
- Modbus || Ethernet
- Net Weight:
- 2.2 kg
- Network Frequency:
- 50/60 Hz
- Wire Stripping Length:
- 16 mm
- Product Name:
- PowerPact H
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Circuit Breaker Application:
- HACR rated
- Ambient Air Temperature For Storage:
- -50-85 °C
- Width:
- 104 mm
- Utilisation Category:
- category A
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- Suitability For Isolation:
- yes IEC 60947-2
- Pollution Degree:
- 3 IEC 60947-1
- Device Application:
- distribution
- Terminal Identifier:
- AL150HD
- Sustainable Offer Status:
- Green Premium product
- Trip Unit Technology:
- thermal-magnetic
- Quantity Per Set:
- 1
- Circularity Profile:
- ENVEOLI1311006EN
- Magnetic Hold Current:
- 800 A
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Rohs Exemption Information:
- Yes
- Product Certifications:
- UL || CSA || NOM
- Height:
- 163 mm
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Magnetic Tripping Current:
- 1450-1450 A
- Ambient Air Temperature For Operation:
- -2-70 °C
- Eu Rohs Directive:
- Compliant
- [Ics] Rated Service Breaking Capacity:
- 65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Depth:
- 86 mm
- Continuous Current Rating:
- 0.8
- Protected Poles Description:
- 3t
- Environmental Disclosure:
- ENVPEP1311006EN
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Quality Labels:
- CE
- Line Rated Current:
- 70-70 A
- Breaking Capacity Code:
- G
