Schneider Electric HJL36045 Molded Case Circuit Breaker 600V 45A
Schneider Electric
$1,949.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric HJL36045 Molded Case Circuit Breaker 600V 45A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 25kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT H, 45A, 3 pole, circuit breaker has a breaking capacity of 25kA at 600VAC. This circuit breaker has a continuous current rating of 80%. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
- Pollution Degree:
- 3 IEC 60947-1
- Trip Unit Technology:
- thermal-magnetic
- Pvc Free:
- Yes
- Local Signalling:
- switched off (OFF) 1 trip indicator green)
- Control Type:
- toggle
- Continuous Current Rating:
- 0.8
- Poles Description:
- 3P
- Wire Stripping Length:
- 16 mm
- Ip Degree Of Protection:
- front cover IP40 IEC 60529
- Range:
- PowerPact
- Network Frequency:
- 50/60 Hz
- Height:
- 163 mm
- Operating Altitude:
- < 6561.68 ft (2000 m) without derating || 5000 m with derating
- Width:
- 104 mm
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Circuit Breaker Application:
- HACR rated
- Utilisation Category:
- category A
- [Ue] Rated Operational Voltage:
- 690 V AC 50/60 Hz IEC 60947-3
- [Ics] Rated Service Breaking Capacity:
- 65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
- Electrical Connection:
- lugs, line || lugs, load
- Ambient Air Temperature For Storage:
- -50-85 °C
- [Ui] Rated Insulation Voltage:
- 750 V IEC 60947-2
- Protected Poles Description:
- 3t
- Rohs Exemption Information:
- Yes
- Terminal Identifier:
- AL150HD
- Magnetic Tripping Current:
- 850-850 A
- Tightening Torque:
- 5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
- Communication Interface:
- Modbus || Ethernet
- Circularity Profile:
- ENVEOLI2206027EN
- [Uimp] Rated Impulse Withstand Voltage:
- 8 kV IEC 60947-2
- Sustainable Offer Status:
- Green Premium product
- Mounting Support:
- lug
- Suitability For Isolation:
- yes IEC 60947-2
- Environmental Disclosure:
- ENVPEP2206027EN
- Line Rated Current:
- 45-45 A
- Quality Labels:
- CE
- Product Certifications:
- UL || CSA || NOM
- Breaking Capacity:
- 100 kA 240 V AC 50/60 Hz UL 489 || 65 kA 480 V AC 50/60 Hz UL 489 || 25 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489
- Magnetic Hold Current:
- 400 A
- Standards:
- UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
- Breaking Capacity Code:
- J
- Quantity Per Set:
- 1
- Device Application:
- distribution
- Warranty:
- 18 months
- Product Name:
- PowerPact H
- Mounting Mode:
- unit mount lug)
- Mercury Free:
- Yes
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
- Product Or Component Type:
- circuit breaker
- Depth:
- 86 mm
- Color:
- Black
- Eu Rohs Directive:
- Compliant with Exemptions
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Net Weight:
- 2.2 kg
- Awg Gauge:
- AWG 14...AWG 3/0 aluminium/copper terminal
- Number Of Slots:
- 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
- Ambient Air Temperature For Operation:
- -2-70 °C
