Schneider Electric HLA36035 Molded Case Circuit Breaker 600V 35A

Schneider Electric HLA36035 Molded Case Circuit Breaker 600V 35A

Schneider Electric
SKU:
HLA36035
|
UPC:
785901422297
Availability:
Contact us to confirm availability and lead times.
$2,993.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 35A, 3 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Warranty:
18 months
Mounting Support:
bracket
Rohs Exemption Information:
Yes
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
Pollution Degree:
3 IEC 60947-1
Ip Degree Of Protection:
front cover IP40 IEC 60529
Product Certifications:
UL || CSA || NOM
Pvc Free:
Yes
Breaking Capacity Code:
L
[Ics] Rated Service Breaking Capacity:
125 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 100 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 50 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Control Type:
toggle
Terminal Identifier:
AL150HD
Mounting Mode:
I-Line bracket)
Circuit Breaker Application:
HACR rated
Quantity Per Set:
1
Breaking Capacity:
125 kA 240 V AC 50/60 Hz UL 489 || 100 kA 480 V AC 50/60 Hz UL 489 || 50 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 50 kA 500 V DC UL 489
Height:
163 mm
Ambient Air Temperature For Operation:
-2-70 °C
Range:
PowerPact
Phase Connection:
ABC
Continuous Current Rating:
0.8
Mounting Height:
4.5 in
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Wire Stripping Length:
16 mm
Network Frequency:
50/60 Hz
Width:
104 mm
Magnetic Tripping Current:
850-850 A
Mercury Free:
Yes
Line Rated Current:
35-35 A
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Electrical Connection:
I-Line connection, line || lugs, load
Color:
Black
Environmental Disclosure:
ENVPEP2206027EN
Communication Interface:
Modbus || Ethernet
Product Name:
PowerPact H
Suitability For Isolation:
yes IEC 60947-2
Sustainable Offer Status:
Green Premium product
Circularity Profile:
ENVEOLI2206027EN
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Utilisation Category:
category A
Ambient Air Temperature For Storage:
-50-85 °C
Magnetic Hold Current:
400 A
Protected Poles Description:
3t
Depth:
86 mm
Device Application:
distribution
Quality Labels:
CE
Net Weight:
2.2 kg
Eu Rohs Directive:
Compliant with Exemptions
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Poles Description:
3P
Product Or Component Type:
circuit breaker
Trip Unit Technology:
thermal-magnetic
Local Signalling:
switched off (OFF) 1 trip indicator green)
