Schneider Electric HLA36110 Molded Case Circuit Breaker 600V 110A

Schneider Electric HLA36110 Molded Case Circuit Breaker 600V 110A

Schneider Electric
SKU:
HLA36110
|
UPC:
785901507192
Availability:
Factory stock
$4,705.29
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
PowerPacT H-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT H-Frame circuit breakers are available with either thermal magnetic or Micrologic electronic trip protection units. This PowerPacT H-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT H-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT H circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. PowerPacT H I-Line circuit breakers are available in I-Line construction for easy installation and removal in I-Line applications. This breaker has I-Line terminations on the line side and mechanical lugs on the load side. This PowerPacT H, 110A, 3 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80% with an ABC phase connection. PowerPacT H circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Rohs Exemption Information:
Yes
Phase Connection:
ABC
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Sustainable Offer Status:
Green Premium product
Depth:
86 mm
Eu Rohs Directive:
Compliant with Exemptions
Mounting Height:
4.5 in
Communication Interface:
Modbus || Ethernet
Pollution Degree:
3 IEC 60947-1
Breaking Capacity Code:
L
Magnetic Tripping Current:
1700-1700 A
Terminal Identifier:
AL150HD
Width:
104 mm
Warranty:
18 months
Ip Degree Of Protection:
front cover IP40 IEC 60529
Color:
Black
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Continuous Current Rating:
0.8
Quantity Per Set:
1
Utilisation Category:
category A
Device Application:
distribution
Local Signalling:
switched off (OFF) 1 trip indicator green)
Product Certifications:
UL || CSA || NOM
Network Frequency:
50/60 Hz
Protected Poles Description:
3t
Net Weight:
2.2 kg
Line Rated Current:
110-110 A
Product Or Component Type:
circuit breaker
[Ue] Rated Operational Voltage:
690 V AC 50/60 Hz IEC 60947-3
Product Name:
PowerPact H
Breaking Capacity:
125 kA 240 V AC 50/60 Hz UL 489 || 100 kA 480 V AC 50/60 Hz UL 489 || 50 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 50 kA 500 V DC UL 489
Environmental Disclosure:
ENVPEP2206027EN
Tightening Torque:
5-5 N.m 2.5-6 mm² (AWG 14...AWG 10) || 14-14 N.m 10-95 mm² (AWG 8...AWG 3/0)
Mounting Mode:
I-Line bracket)
Ambient Air Temperature For Operation:
-2-70 °C
[Ics] Rated Service Breaking Capacity:
125 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 100 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 50 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Pvc Free:
Yes
Wire Stripping Length:
16 mm
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
Circularity Profile:
ENVEOLI2206027EN
Quality Labels:
CE
Magnetic Hold Current:
900 A
Range:
PowerPact
Trip Unit Technology:
thermal-magnetic
Electrical Connection:
I-Line connection, line || lugs, load
Poles Description:
3P
Mercury Free:
Yes
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Circuit Breaker Application:
HACR rated
Awg Gauge:
AWG 14...AWG 3/0 aluminium/copper terminal
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
Height:
163 mm
Ambient Air Temperature For Storage:
-50-85 °C
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Suitability For Isolation:
yes IEC 60947-2
Mounting Support:
bracket
Control Type:
toggle
