Schneider Electric JDL36200SK Molded Case Circuit Breaker 600V 200A

(No reviews yet) Write a Review

Write a Review

Schneider Electric JDL36200SK Molded Case Circuit Breaker 600V 200A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

JDL36200SK

UPC:

3.60649E+12

MPN:

Condition:

New

[Ics] Rated Service Breaking Capacity:

25 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 18 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 14 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2

Control Type:

toggle

[Ui] Rated Insulation Voltage:

750 V IEC 60947-2

Operating Altitude:

< 6561.68 ft (2000 m) without derating || 5000 m with derating

Mounting Mode:

unit mount lug)

Ambient Air Temperature For Operation:

-2-70 °C

Line Rated Current:

200-200 A

Depth:

86 mm

Long Time Pick-Up Adjustment Range:

0.25...1 x In

Wire Stripping Length:

25 mm

Sustainable Offer Status:

Green Premium product

Product Name:

PowerPact J

Trip Unit Technology:

thermal-magnetic

Pollution Degree:

3 IEC 60947-1

Network Frequency:

50/60 Hz

Accessory / Separate Part Type:

shunt trip 24 V AC compartment

Circuit Breaker Application:

HACR rated

Circularity Profile:

ENVEOLI2206031EN

Local Signalling:

switched off (OFF) 1 trip indicator green)

Electrical Connection:

lugs, line || lugs, load

Width:

104 mm

Standards:

UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2

Terminal Identifier:

AL250JD

Warranty:

18 months

Environmental Disclosure:

ENVPEP2206031EN

Mounting Height:

4.5 in

Ambient Air Temperature For Storage:

-50-85 °C

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Continuous Current Rating:

0.8

Poles Description:

3P

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

Mounting Support:

lug

Mercury Free:

Yes

Pvc Free:

Yes

Breaking Capacity Code:

D

Height:

191 mm

Protection Type:

overload protection || short-circuit protection

Quality Labels:

CE

[Ue] Rated Operational Voltage:

600 V AC 50/60 Hz IEC 60947-3

Eu Rohs Directive:

Compliant with Exemptions

Product Or Component Type:

circuit breaker

California Proposition 65:

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information

Magnetic Hold Current:

1000 A

Communication Interface:

Modbus || Ethernet

Range:

PowerPact

Device Application:

distribution

Tightening Torque:

25-25 N.m 95-185 mm² (AWG 3/0...350 kcmil)

Awg Gauge:

AWG 3/0...350 kcmil aluminium/copper terminals

Number Of Slots:

2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)

Net Weight:

2.4 kg

Ip Degree Of Protection:

front cover IP40

Breaking Capacity:

25 kA 240 V AC 50/60 Hz UL 489 || 18 kA 480 V AC 50/60 Hz || 14 kA 600 V AC 50/60 Hz || 20 kA 250 V DC

Rohs Exemption Information:

Yes

Utilisation Category:

category A

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Suitability For Isolation:

yes IEC 60947-2

Phase Connection:

CA

Magnetic Tripping Current:

2000-2000 A

Product Certifications:

UL || CSA || NOM
