Schneider Electric JLL36250T Molded Case Circuit Breaker 600V 250A

Schneider Electric JLL36250T Molded Case Circuit Breaker 600V 250A

Schneider Electric
SKU:
JLL36250T
|
UPC:
785901660828
$8,993.00
(No reviews yet) Write a Review
Condition:
New
Current Stock:
Description
PowerPacT J-Frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. PowerPacT J-Frame circuit breakers are available with either thermal magnetic or MicroLogic electronic trip protection units. This PowerPacT J-Frame circuit breaker provides thermal magnetic circuit protection with a breaking capacity of 50kA at 600VAC. All PowerPacT J-Frame circuit breakers are equipped with dual-break rotating contacts that reduce the amount of peak current during a short circuit fault. All PowerPacT circuit breakers have an integral push-to-trip button in the cover to manually trip the circuit breaker. PowerPacT J circuit breakers are available in 2 and 3-pole unit mount and I-Line constructions. This breaker has lugs on both the line and load sides. This PowerPacT J, 250A, 3 pole, circuit breaker has a breaking capacity of 50kA at 600VAC. This circuit breaker has a continuous current rating of 80%. This unit allows field-interchangeable trip units. PowerPacT J circuit breakers comply to UL, CSA, NOM, and IEC standards and are CE marked.
Additional Information
Line Rated Current:
250-250 A
Protection Type:
overload protection || short-circuit protection
Net Weight:
2.4 kg
Terminal Identifier:
AL250JD
Magnetic Hold Current:
1250 A
Pollution Degree:
3
[Ue] Rated Operational Voltage:
600 V AC 50/60 Hz IEC 60947-3
Wire Stripping Length:
25 mm
Long Time Pick-Up Adjustment Range:
0.25...1 x In
Sustainable Offer Status:
Green Premium product
Communication Interface:
Modbus
Network Frequency:
50/60 Hz
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Circularity Profile:
ENVEOLI2206031EN
Continuous Current Rating:
0.8
Rohs Exemption Information:
Yes
Ambient Air Temperature For Storage:
-50-85 °C
Control Type:
toggle
Height:
191 mm
[Ui] Rated Insulation Voltage:
750 V IEC 60947-2
Quality Labels:
CE
Suitability For Isolation:
yes IEC 60947-2
Poles Description:
3P
Pvc Free:
Yes
Ip Degree Of Protection:
front cover IP40
Eu Rohs Directive:
Compliant with Exemptions
Product Or Component Type:
circuit breaker
Magnetic Tripping Current:
2500-2500 A
Mounting Support:
lug
Circuit Breaker Application:
HACR rated
[Uimp] Rated Impulse Withstand Voltage:
8 kV IEC 60947-2
Breaking Capacity Code:
L
Operating Altitude:
< 6561.68 ft (2000 m) without derating || 5000 m with derating
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Mercury Free:
Yes
Local Signalling:
switched off (OFF) 1 trip indicator green)
Ambient Air Temperature For Operation:
-2-70 °C
Warranty:
18 months
Tightening Torque:
25-25 N.m 95-185 mm² (AWG 3/0...350 kcmil)
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Environmental Disclosure:
ENVPEP2206031EN
Standards:
UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
[Ics] Rated Service Breaking Capacity:
125 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 100 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 50 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
Utilisation Category:
category A
Product Certifications:
UL || CSA || NOM
Electrical Connection:
lugs, line || lugs, load
Width:
104 mm
Mounting Mode:
unit mount lug)
Trip Unit Technology:
thermal-magnetic
Depth:
86 mm
Awg Gauge:
AWG 3/0...350 kcmil aluminium/copper terminals
Breaking Capacity:
125 kA 240 V AC 50/60 Hz UL 489 || 100 kA 480 V AC 50/60 Hz UL 489 || 50 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 50 kA 500 V DC UL 489
Number Of Slots:
2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
