Schneider Electric LA36200 Molded Case Circuit Breaker 600V 200A

Schneider Electric LA36200 Molded Case Circuit Breaker 600V 200A

Schneider Electric
SKU:
LA36200
|
UPC:
785901339298
Availability:
Contact us to confirm availability and lead times.
$4,944.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
Square D FA/LA Molded Case Circuit Breakers is designed to protect electrical systems from damage caused by overloads. For distribution systems supplied by transformers and distribution systems supplied by engine generator sets.
Additional Information
Mounting Mode:
I-Line
Terminal Identifier:
AL400LA
Magnetic Tripping Current:
2000-2000 A
Magnetic Hold Current:
1000 A
Eu Rohs Directive:
Compliant with Exemptions
Product Certifications:
UL Listed || CSA
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Environmental Disclosure:
ENVPEP1410004EN
Line Rated Current:
200 A
Height:
11 in
Halogen Content Performance:
Halogen free plastic parts product
Breaking Capacity Code:
A
Circuit Breaker Application:
HACR rated
Poles Description:
3P
Electrical Connection:
lugs, load || I-Line connection, line
California Proposition 65:
WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information
Rohs Exemption Information:
Yes
Circularity Profile:
N/A
Mercury Free:
Yes
Product Or Component Type:
circuit breaker
Warranty:
18 months
Wiring Configuration:
3-wire
Pvc Free:
Yes
Sustainable Offer Status:
Green Premium product
Depth:
5.84 in
Trip Unit Technology:
thermal-magnetic
Width:
6 in
