Schneider Electric LV426850 Coil Mx
Schneider Electric
$620.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This standard MX shunt trip is used on Compact NSXm and PowerPact B devices. This auxiliary is used for emergency off or failsafe remote opening applications. It is a one click spring type auxiliary for quick and easy installation, visible from the front face of the device. This MX auxiliary has a 12 VDC rated voltage. It trips the circuit breaker when the control voltage rises above 70% of its rated value. It complies with IEC 60947-2 standard. Compact NSXm and PowerPact B embed either 1 MN or 1 MX coil.
- [Uc] Control Circuit Voltage:
- 12 V DC
- Device Application:
- control
- Eu Rohs Directive:
- Compliant with Exemptions
- California Proposition 65:
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Response Time:
- < 50 ms
- Sustainable Offer Status:
- Green Premium product
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Threshold Tripping Voltage:
- 0.7 Un opening
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Product Or Component Type:
- voltage release
- Auxiliary Connection Terminal:
- spring
- Circularity Profile:
- ENVEOLI2311043EN
- Rohs Exemption Information:
- Yes
- Control Signal Type:
- maintained || impulse
- Impulse Duration:
- >= 20 ms
- Range:
- ComPact
- Range Of Product:
- ComPacT NSXm new generation
- Voltage Release Type:
- opening coil || shunt trip release
- Device Short Name:
- MX
- Control Type:
- standard
- Mercury Free:
- Yes
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Environmental Disclosure:
- ENVPEP2311043EN
- Range Compatibility:
- ComPact ComPacT NSXm new generation || ComPact ComPact NSXm || PowerPact PowerPact B
- Datasheet:
- View
