Schneider Electric M9A26478 Multi9 Mx 12-24Vac 12-24Vdc Shunt
This Multi9 MX electrical auxiliary is a shunt trip release. It is dedicated to Multi9 GFP, C60BP, C60SP, C60BPR. The width in 9mm pitches is 2. The Uc control circuit voltage is 12VAC to 24VAC, or 12VDC to 24VDC. It can be mounted on a DIN rail for modular installation. The operating temperature is -25°C to 50°C. The storage temperature is -40°C to 85°C. This product complies with EN/IEC 60947-1 standard.
- Standards:
- EN/IEC 60947-1
- Rohs Exemption Information:
- Yes
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Environmental Disclosure:
- ENVPEP1305024
- Eu Rohs Directive:
- Compliant
- Range Compatibility:
- Multi 9 Multi9 C60 C60BP || Multi 9 Multi9 C60 C60BPR || Multi 9 Multi9 C60 C60SP || Multi 9 Multi9 GFP GFP || Multi 9 Multi9 C60H-DC C60H-DC
- Circularity Profile:
- N/A
- Local Signalling:
- action indicator
- 9 Mm Pitches:
- 2
- Range:
- Multi9
- Sustainable Offer Status:
- Green Premium product
- Pollution Degree:
- 3
- Toxic Heavy Metal Free:
- Yes
- Net Weight:
- 0.06 kg
- Mounting Mode:
- fixed
- Comb Busbar And Distribution Block Compatibility:
- top YES
- Product Certifications:
- UR || PCT || UL
- Ambient Air Temperature For Operation:
- -25-50 °C
- Width:
- 18 mm
- Ambient Air Temperature For Storage:
- -40-85 °C
- Tropicalisation:
- 2 EN/IEC 60947-1
- Wire Stripping Length:
- 9 mm for bottom connection
- Tightening Torque:
- 1-1 N.m bottom
- Mercury Free:
- Yes
- Mounting Support:
- DIN rail
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Product Or Component Type:
- shunt trip release
- Depth:
- 68 mm
- Device Short Name:
- MX
- [Uc] Control Circuit Voltage:
- 12...24 V AC 50/60 Hz || 12...24 V DC
- Connections - Terminals:
- clamp terminal bottom) - 1 2.5-2.5 mm² AWG 14) - rigid || clamp terminal bottom) - 2 1.5-1.5 mm² AWG 16) - rigid
- Reach Free Of Svhc:
- Yes
- Height:
- 82.5 mm
- Relative Humidity:
- 95-95 % 55-55 °C
