Schneider Electric M9A27108 Multi9 Mn 24Vac/Vdc Undervoltage Release
Schneider Electric
$201.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This Acti9 MN electrical auxiliary is a undervoltage release device. It is dedicated to Multi9 GFP, C60BP, C60SP, C60BPR. It prevents device closing again until its input voltage has been restored. The width in 9mm pitches is 2. The Uc control circuit voltage is 24VAC or 24VDC. It can be mounted on a DIN rail for modular installation. The operating temperature is -25°C to + 50°C. The storage temperature is -40°C to + 85°C. This product complies with EN/IEC 60947-1 standards.
- Rohs Exemption Information:
- Yes
- Connections - Terminals:
- clamp terminal bottom) - 1 2.5-2.5 mm² AWG 14) - rigid || clamp terminal bottom) - 2 1.5-1.5 mm² AWG 16) - rigid
- Ambient Air Temperature For Operation:
- -25-50 °C
- Circularity Profile:
- ENVEOLI1305023
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Range:
- Multi9
- Pollution Degree:
- 3
- Width:
- 18 mm
- Mounting Mode:
- fixed
- Mounting Support:
- DIN rail
- Device Short Name:
- MN
- Eu Rohs Directive:
- Compliant with Exemptions
- [Uc] Control Circuit Voltage:
- 24 V AC 50/60 Hz || 24 V DC
- Product Or Component Type:
- undervoltage release
- Standards:
- EN/IEC 60947-1 || EN 60947-2
- Environmental Disclosure:
- ENVPEP1305023
- Mercury Free:
- Yes
- Sustainable Offer Status:
- Green Premium product
- Tightening Torque:
- 1-1 N.m bottom
- 9 Mm Pitches:
- 2
- Wire Stripping Length:
- 9 mm for bottom connection
- Range Compatibility:
- Multi 9 Multi9 C60 C60BP || Multi 9 Multi9 C60 C60BPR || Multi 9 Multi9 C60 C60SP || Multi 9 Multi9 GFP GFP || Multi 9 Multi9 C60H-DC C60H-DC
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Control Type:
- standard
- Depth:
- 68 mm
- Comb Busbar And Distribution Block Compatibility:
- top YES
- Net Weight:
- 0.066 kg
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Product Certifications:
- PCT || UR || UL
- Height:
- 82.5 mm
- Local Signalling:
- action indicator
- Ambient Air Temperature For Storage:
- -40-85 °C
