Schneider Electric M9XCP157 Multi9 1P 57 Modules Ul508 Comb Busbar
Schneider Electric
$1,069.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric M9XCP157 Multi9 1P 57 Modules Ul508 Comb Busbar
This Multi9 product is a cuttable horizontal comb busbar 57 modules for Multi9 C60 BP. It is dedicated to (Line) installations. The distribution type is 1L. It is a set of 1 device. The length is 1026mm. The total number of modules of 18mm is 57. The Ue rated operational voltage is 277VAC (phase to neutral) and 480VAC (phase to phase). The Ui rated insulation voltage is 1000VAC. The color is light grey (RAL 7035). The degree of protection is IP20 with end-pieces and tooth covers. The pollution degree is 3. The resistance of the plastic to flames and to abnormal heat is 960°C within 30s conforming to IEC 60695-2-1. It complies with UL 508 standard.
- [Ie] Rated Operational Current:
- 80 A 40 °C
- [Ue] Rated Operational Voltage:
- 480 V AC 50/60 Hz Ph/Ph || 277 V AC 50/60 Hz Ph/N
- Fire Resistance:
- 960 °C 30 s ) IEC 60695-2-1
- Number Of Ways:
- 57 ways 1 L
- Insulation:
- insulated
- Eu Rohs Directive:
- Compliant
- Pollution Degree:
- 3
- Color:
- Light gray RAL 7035)
- Toxic Heavy Metal Free:
- Yes
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Standards:
- UL 508
- Range:
- Multi9
- Product Or Component Type:
- comb busbar
- Width:
- 1026 mm
- Range Compatibility:
- Multi9 Multi9 C60BP
- Reach Free Of Svhc:
- Yes
- Mounting Mode:
- horizontal
- Distance Between Way:
- 18 mm
- Accessory / Separate Part Category:
- connection accessory
- Rohs Exemption Information:
- Yes
- 9 Mm Pitches:
- 114
- Connection Pitch:
- 18 mm
- [Ui] Rated Insulation Voltage:
- 1000 V AC 50/60 Hz UL 508
- Connector Type:
- tooth
- Device Presentation:
- cuttable
- China Rohs Regulation:
- Pro-active China RoHS declaration (out of China RoHS legal scope)
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Poles Configuration For 1 Way:
- 1 x 1P
- Ip Degree Of Protection:
- IP20 with end-pieces and tooth covers
- Lines Description:
- 1L
- Mounting Location:
- top tunnel type terminals
- Total Number Of 18 Mm Modules:
- 57
- Mercury Free:
- Yes
