Schneider Electric PJA36040U44A Molded Case Circuit Breaker 600V 400A

(No reviews yet) Write a Review

Write a Review

Schneider Electric PJA36040U44A Molded Case Circuit Breaker 600V 400A

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

PJA36040U44A

UPC:

785901002963

MPN:

Condition:

New

Standards:

UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2

Mercury Free:

Yes

Trip Unit Name:

MicroLogic 6.0 A

Phase Connection:

ABC

Awg Gauge:

3 x AWG 3/0...500 kcmil aluminium/copper

Mounting Mode:

I-Line bracket)

Height:

12.86 in

Quantity Per Set:

1

Trip Unit Technology:

electronic, ammeter, MicroLogic 6.0 A, LSIG

China Rohs Regulation:

Product out of China RoHS scope. Substance declaration for your information.

Net Weight:

32 lb(US)

Line Rated Current:

400-400 A

Product Or Component Type:

circuit breaker

Mounting Support:

bracket

Quality Labels:

CE

Sustainable Offer Status:

Green Premium product

[Ui] Rated Insulation Voltage:

750 V IEC 60947-2

Network Frequency:

50/60 Hz

Local Signalling:

1 trip indicator green)

[Ue] Rated Operational Voltage:

600 V AC 50/60 Hz UL 489

Terminal Identifier:

AL800M23K

Operating Altitude:

< 6561.68 ft (2000 m) without derating || 13123.36 ft (4000 m) with derating

Wire Stripping Length:

25 mm

Continuous Current Rating:

0.8

Pvc Free:

Yes

Ip Degree Of Protection:

front cover IP40

Warranty:

18 months

Environmental Disclosure:

ENVPEP2206033EN

Product Certifications:

UL || CSA || NOM

Mounting Height:

9 in

[Ics] Rated Service Breaking Capacity:

35 kA 240 V AC 50/60 Hz IEC 60947-2 || 25 kA 380/415 V AC 50/60 Hz IEC 60947-2

Breaking Capacity Code:

J

Poles Description:

3P

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Long Time Pick-Up Adjustment Range:

0.4...1 x Ir

Control Type:

toggle

Tightening Torque:

50-50 N.m 95-240 mm² (3 x AWG 3/0...500 kcmil) || 1.0-1.3 N.m

Width:

8.27 in

Breaking Capacity:

AIR 100 kA 240 V AC 50/60 Hz UL 489 || AIR 65 kA 480 V AC 50/60 Hz UL 489 || AIR 25 kA 600 V AC 50/60 Hz UL 489 || Icu 65 kA 240 V AC 50/60 Hz IEC 60947-2 || Icu 50 kA 380/415 V AC 50/60 Hz IEC 60947-2

[Uimp] Rated Impulse Withstand Voltage:

8 kV IEC 60947-2

Circularity Profile:

ENVEOLI2206033EN

Circuit Breaker Application:

HACR rated

Electrical Connection:

I-Line connection, line || lugs, load

Device Application:

distribution

Range:

PowerPact

Pollution Degree:

3 IEC 60947-1

Rohs Exemption Information:

Yes

Eu Rohs Directive:

Compliant with Exemptions

Product Name:

PowerPact P

Depth:

8.05 in

Number Of Slots:

2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)

Ambient Air Temperature For Storage:

-50-85 °C

Ambient Air Temperature For Operation:

-2-70 °C

California Proposition 65:

WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information

Brochure:

View

Catalog:

View

Datasheet:

View
