Schneider Electric QHB130 Mini Circuit Breaker, 120/240V 30A
Schneider Electric
$122.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QHB130 Mini Circuit Breaker, 120/240V 30A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 65kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- Eu Rohs Directive:
- Compliant with Exemptions
- Product Or Component Type:
- miniature circuit-breaker
- Poles Description:
- 1P
- Mounting Mode:
- bolt-on
- Warranty:
- 18 months
- Ambient Air Temperature For Operation:
- 40 °C
- Circularity Profile:
- N/A
- Circuit Breaker Application:
- HACR rated
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Product Certifications:
- UL Listed || CSA
- Range Of Product:
- QO
- Circuit Breaker Type:
- standard
- Number Of Spaces Required:
- 1
- Halogen Content Performance:
- Halogen free product
- Width:
- 19 mm
- Height:
- 76 mm
- Sustainable Offer Status:
- Green Premium product
- Breaking Capacity:
- 65 kA 120/240 V AC 50/60 Hz || 65 kA 120 V AC 50/60 Hz
- Toxic Heavy Metal Free:
- Yes
- Depth:
- 74 mm
- Electrical Connection:
- pressure plate
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Net Weight:
- 0.136 kg
- Line Rated Current:
- 30 A
- Tightening Torque:
- 4.6-4.6 N.m
- Mercury Free:
- Yes
- Rohs Exemption Information:
- Yes
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 120 V AC
