Schneider Electric QOB1201044 Miniature Circuit Breaker 120/240V 20A

(No reviews yet) Write a Review
SKU:
QOB1201044
UPC:
3606486146392
Condition:
New
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Line Rated Current:
20 A
Toxic Heavy Metal Free:
Yes
Range Of Product:
QO
China Rohs Regulation:
Product out of China RoHS scope. Substance declaration for your information.
Poles Description:
1P
Circuit Breaker Application:
HACR and Switching Duty rated
Mounting Mode:
bolt-on
Height:
76 mm
Ambient Air Temperature For Operation:
40 °C
Rohs Exemption Information:
Yes
Eu Rohs Directive:
Compliant with Exemptions
Accessory / Separate Part Type:
shunt trip 12/24 V AC/DC
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Product Certifications:
UL Listed || CSA
Breaking Capacity:
10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
Net Weight:
0.136 kg
Depth:
74 mm
Width:
38 mm
Awg Gauge:
AWG 14...AWG 8 copper or aluminium
Electrical Connection:
pressure plate
[Ue] Rated Operational Voltage:
120/240 V AC || 120 V AC
Number Of Spaces Required:
2
Product Or Component Type:
miniature circuit-breaker
Tightening Torque:
4-4 N.m
Circuit Breaker Type:
standard
Mercury Free:
Yes
$236.80

Description

QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 20A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an AC/DC shunt trip. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
