Schneider Electric QOB1205237 Miniature Circuit Breaker 120/240V 20A
Schneider Electric
$47.70
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOB1205237 Miniature Circuit Breaker 120/240V 20A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 20A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes ring terminals. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Product Or Component Type:
- miniature circuit-breaker
- Mounting Mode:
- bolt-on
- Awg Gauge:
- AWG 14...AWG 8 copper
- Mercury Free:
- Yes
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- Range Of Product:
- QO
- Toxic Heavy Metal Free:
- Yes
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 120 V AC
- Circularity Profile:
- N/A
- Number Of Spaces Required:
- 1
- Circuit Breaker Type:
- standard
- Eu Rohs Directive:
- Compliant with Exemptions
- Product Certifications:
- UL Listed || CSA
- Width:
- 19 mm
- Sustainable Offer Status:
- Green Premium product
- Halogen Content Performance:
- Halogen free product
- Tightening Torque:
- 4-4 N.m
- Line Rated Current:
- 20 A
- Net Weight:
- 0.145 kg
- Poles Description:
- 1P
- Circuit Breaker Application:
- HACR rated
- Rohs Exemption Information:
- Yes
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Ambient Air Temperature For Operation:
- 40 °C
- Electrical Connection:
- ring tongue
- Warranty:
- 18 months
- Depth:
- 74 mm
- Height:
- 76 mm
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 5 kA 120 V AC 50/60 Hz
