Schneider Electric QOB140FT Miniature Circuit Breaker 120/240V 40A
Schneider Electric
$47.80
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOB140FT Miniature Circuit Breaker 120/240V 40A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 1 pole QO circuit breaker is rated at 40A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a fungal treatment. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Poles Description:
- 1P
- Awg Gauge:
- AWG 8...AWG 2 copper or aluminium
- Height:
- 79 mm
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- Ambient Air Temperature For Operation:
- 50 °C
- Eu Rohs Directive:
- Compliant with Exemptions
- Net Weight:
- 0.145 kg
- Mercury Free:
- Yes
- Range Of Product:
- QO
- Rohs Exemption Information:
- Yes
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 120 V AC
- Product Certifications:
- UL Listed || CSA
- Depth:
- 74 mm
- Electrical Connection:
- box lugs
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Circuit Breaker Type:
- standard
- Number Of Spaces Required:
- 1
- Warranty:
- 18 months
- Mounting Mode:
- bolt-on
- Width:
- 19 mm
- Toxic Heavy Metal Free:
- Yes
- Product Or Component Type:
- miniature circuit-breaker
- Tightening Torque:
- 5-5 N.m
- Line Rated Current:
- 40 A
- Circuit Breaker Application:
- HACR rated
- Brochure:
- View
- Catalog:
- View
- Datasheet:
- View
