Schneider Electric QOB225H Miniature Circuit Breaker 240V 25A
Schneider Electric
$360.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 25A at 240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Warranty:
- 18 months
- Poles Description:
- 2P
- Height:
- 76 mm
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- Ambient Air Temperature For Operation:
- 40 °C
- Circularity Profile:
- N/A
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- Eu Rohs Directive:
- Compliant with Exemptions
- Net Weight:
- 0.277 kg
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC
- Circuit Breaker Application:
- HACR rated
- Mercury Free:
- Yes
- Line Rated Current:
- 25 A
- Circuit Breaker Type:
- standard
- Mounting Mode:
- bolt-on
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Sustainable Offer Status:
- Green Premium product
- Product Certifications:
- UL Listed || CSA
- Electrical Connection:
- pressure plate
- Number Of Spaces Required:
- 2
- Tightening Torque:
- 4.6-4.6 N.m
- Width:
- 38 mm
- Toxic Heavy Metal Free:
- Yes
- Product Or Component Type:
- miniature circuit-breaker
- Range Of Product:
- QO
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Depth:
- 74 mm
- Rohs Exemption Information:
- Yes
