Schneider Electric QOB230HID Miniature Circuit Breaker 240V 30A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product has a high density discharge feature. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Circuit Breaker Type:
- high intensity discharge
- Sustainable Offer Status:
- Green Premium product
- Warranty:
- 18 months
- Electrical Connection:
- pressure plate
- Number Of Spaces Required:
- 2
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Ambient Air Temperature For Operation:
- 40 °C
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Circularity Profile:
- N/A
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Net Weight:
- 0.254 kg
- Height:
- 76 mm
- Halogen Content Performance:
- Halogen free product
- [Ue] Rated Operational Voltage:
- 120/240 V AC
- Product Certifications:
- UL Listed || CSA
- Mounting Mode:
- bolt-on
- Range Of Product:
- QO
- Width:
- 38 mm
- Line Rated Current:
- 30 A
- Circuit Breaker Application:
- not rated
- Depth:
- 74 mm
- Tightening Torque:
- 4-4 N.m
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz
- Poles Description:
- 2P
- Product Or Component Type:
- miniature circuit-breaker
- Mercury Free:
- Yes
- Eu Rohs Directive:
- Compliant with Exemptions
- Rohs Exemption Information:
- Yes
