Schneider Electric QOB2451021 Miniature Circuit Breaker 120/240V 45A
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 2 pole QO circuit breaker is rated at 45A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an AC shunt trip. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Environmental Disclosure:
- ENVPEP1304033
- Circuit Breaker Application:
- HACR rated
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 120 V AC
- Reach Free Of Svhc:
- Yes
- Toxic Heavy Metal Free:
- Yes
- China Rohs Regulation:
- X
- Product Certifications:
- UL Listed || CSA
- Mounting Mode:
- bolt-on
- Height:
- 79 mm
- Range Of Product:
- QO
- Electrical Connection:
- box lugs
- Sustainable Offer Status:
- Green Premium product
- Mercury Free:
- Yes
- Ambient Air Temperature For Operation:
- 40 °C
- Line Rated Current:
- 45 A
- Net Weight:
- 0.435 kg
- Circuit Breaker Type:
- standard
- Depth:
- 74 mm
- Warranty:
- 18 months
- Accessory / Separate Part Type:
- shunt trip 120/208/240 V AC
- Halogen Content Performance:
- Halogen free product
- Product Or Component Type:
- miniature circuit-breaker
- Eu Rohs Directive:
- Compliant
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- Rohs Exemption Information:
- Yes
- Width:
- 57 mm
- Awg Gauge:
- AWG 8...AWG 2 copper or aluminium
- Number Of Spaces Required:
- 3
- Poles Description:
- 2P
- Tightening Torque:
- 5-5 N.m
