Schneider Electric QOB3301200 Miniature Circuit Breaker 240V 30A
Schneider Electric
$425.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric QOB3301200 Miniature Circuit Breaker 240V 30A
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes an auxiliary switch 1A. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
- Circuit Breaker Type:
- standard
- Range Of Product:
- QO
- Width:
- 76 mm
- Product Or Component Type:
- miniature circuit-breaker
- Circuit Breaker Application:
- HACR rated
- Depth:
- 74 mm
- Tightening Torque:
- 4-4 N.m
- Warranty:
- 18 months
- Ambient Air Temperature For Operation:
- 40 °C
- Accessory / Separate Part Type:
- auxiliary switch 120 V AC 1A
- Eu Rohs Directive:
- Under investigation
- Number Of Spaces Required:
- 4
- Net Weight:
- 0.549 kg
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Electrical Connection:
- pressure plate
- Breaking Capacity:
- 10 kA 120/240 V AC 50/60 Hz || 10 kA 240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
- Awg Gauge:
- AWG 14...AWG 8 copper or aluminium
- Poles Description:
- 3P
- Mounting Mode:
- bolt-on
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC
- Height:
- 76 mm
- Product Certifications:
- UL Listed || CSA
- Line Rated Current:
- 30 A
