Schneider Electric QOU3105283 Miniature Circuit Breaker 240V 10A
Schneider Electric
$354.00
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
QOU unit mount miniature circuit breakers (cable-in/cable-out) are ideal for OEM applications. QOU breakers are one, two or three pole thermal magnetic circuit breakers which provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. These QOU miniature circuit breakers can be DIN rail mounted, surface mounted or flush mounted using mounting feet. This three pole QOU miniature circuit breaker is rated as 10A, 240 VAC. This circuit breaker provides 10 kA breaking capacity. A full line of accessories are available for these circuit breakers. The ring tongue connectors will accept one 14 AWG to 2/0 AWG copper or aluminum wire. This circuit breaker has a maximum height of 4.05 inches, a maximum width of 2.25 inches and maximum depth of 2.95 inches. QOU circuit breakers are UL Listed and CSA Certified.
- China Rohs Regulation:
- Product out of China RoHS scope. Substance declaration for your information.
- Electrical Connection:
- ring tongue, line side || ring tongue, load side
- Width:
- 2.25 in
- Warranty:
- 18 months
- Mercury Free:
- Yes
- Range Of Product:
- QOU
- Tightening Torque:
- 45-45 lbf.in (AWG 14...AWG 2)
- Height:
- 4.05 in
- Toxic Heavy Metal Free:
- Yes
- Product Or Component Type:
- miniature circuit-breaker
- Rohs Exemption Information:
- Yes
- Product Certifications:
- CSA || UL Listed || IEC
- Line Rated Current:
- 0.416666666666667
- Depth:
- 2.95 in
- [Ue] Rated Operational Voltage:
- 120/240 V AC || 240 V AC || 120 V AC || 48 V DC
- Eu Rohs Directive:
- Compliant with Exemptions
- Circuit Breaker Application:
- HACR rated
- Circularity Profile:
- N/A
- Halogen Content Performance:
- Halogen free product
- Awg Gauge:
- AWG 14...AWG 2 aluminium/copper
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Sustainable Offer Status:
- Green Premium product
- Mounting Mode:
- unit mount
- Circuit Breaker Type:
- standard
- Datasheet:
- View
