Schneider Electric REXL2TMB7 Mini Plug-In Timer 2C/O 24Vac

(No reviews yet) Write a Review

Write a Review

Schneider Electric REXL2TMB7 Mini Plug-In Timer 2C/O 24Vac

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

REXL2TMB7

UPC:

3389119400022

MPN:

Condition:

New

Immunity To Voltage Dips:

>= 95 % / 1 s IEC 61000-4-11 || 30 % / 10 ms IEC 61000-4-11 || 60 % / 100 ms IEC 61000-4-11

Range Of Product:

Harmony Timer Relays

Fixing Mode:

plug-in socket)

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Voltage Range:

0.85...1.15 Us

Ambient Air Temperature For Operation:

-20-60 °C

Mercury Free:

Yes

Sustainable Offer Status:

Green Premium product

Net Weight:

0.05 kg

Resistance To Electrostatic Discharge:

6 kV in contact IEC 61000-4-2 level 3 || 8 kV in air IEC 61000-4-2 level 3

China Rohs Regulation:

X

Temperature Drift:

0.05 %/°C

Output Overvoltage Protection:

2 J

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Standards:

EN 50081-2 || IEC 61000-6-2 || IEC 60601-2 || IEC 61812-1 || 93/68/EEC || 73/23/EEC || 89/336/EEC || IEC 60601-1

Resistance To Electromagnetic Fields:

10 V/m IEC 61000-4-3 level 3

Vibration Resistance:

0.35 mm 10-55 Hz)IEC 60068-2-6

Disturbance Radiated/Conducted:

class B EN 55022 (EN 55011 group 1)

Product Certifications:

UL || cUL

Contacts Type And Composition:

2 C/O

Maximum Switching Capacity:

4 x 5 A

[Ui] Rated Insulation Voltage:

250 V IEC 255 Group C || 250 V VDE 0010

Rohs Exemption Information:

Yes

Power Consumption In Va:

1.7 VA

Relative Humidity:

95-95 % without condensation IEC 60068-2-6

Electrical Durability:

100000 cycles 250 V AC resistive

Setting Accuracy Of Time Delay:

10 % at full scale 25 °C IEC 61812-1

Local Signalling:

for output in operation 1 LED (red) || for power ON 1 LED (yellow)

Surge Withstand:

2 kV IEC 61000-4-5 level 3

Contacts Material:

cadmium free

Minimum Switching Current:

100 mA

Discrete Output Type:

relay

Immunity To Microbreaks:

5 ms

Repeat Accuracy:

+/- 0.5 %

Circularity Profile:

N/A

Product Or Component Type:

single function relay

Line Rated Current:

5 A AC

Creepage Distance:

4 kV/3 IEC 60664-1

Dielectric Strength:

2 kV 1 mA/1 minute 50 Hz IEC 60601-1 || 2 kV 1 mA/1 minute 50 Hz IEC 61812-1

California Proposition 65:

WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other repr

Warranty:

18 months

Reset Time:

250 ms after time delay, on de-energisation || 50 ms during time delay, on de-energisation

[Us] Rated Supply Voltage:

24 V AC 50/60 Hz

Temporary Permissible Current:

10 A < 10 s

Mechanical Durability:

10000000 cycles

Environmental Disclosure:

ENVPEP1310019EN

Component Name:

REXL

Time Delay Type:

power on-delay

Time Delay Range:

10...100 h || 6...60 min || 0.1...1 s || 1...10 h || 1...10 min || 6...60 s || 1...10 s

Immunity To Radioelectric Fields:

10 V 0.15...80 MHz)IEC 61000-4-6 level 3

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Ambient Air Temperature For Storage:

-40-70 °C

Ip Degree Of Protection:

IP50 conforming to IEC 60529

Resistance To Fast Transients:

2 kV IEC 61000-4-4 level 3

Voltage Drift:

+/- 0.2 %/V
