Schneider Electric VW3A3202 Extended I O Card

Schneider Electric VW3A3202 Extended I O Card

Schneider Electric
SKU:
VW3A3202
|
UPC:
3389118067110
Availability:
Contact us to confirm availability and lead times.
$238.64
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This extended I/O card enables your drive to meet the needs of more complex or extensive applications. It comprises four logic inputs, two analog inputs, one input for PTC probe and one frequency control input. It also comprises three logic outputs and two analog outputs. It is compatible with Altivar 61 and Altivar 71.
Additional Information
Electrical Durability:
100000 cycles configurable relay logic
Discrete Input Voltage:
24 V DC <= 30 V)programmable
Net Weight:
0.3 kg
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Ptc Probe Input:
TH2+, TH2- trip resistance 3 kOhm || TH2+, TH2- reset resistance 1.8 Ohm || TH2+, TH2- short circuit protection < 0.05 Ohm || TH2+, TH2- for 6 PTC probe <= 1.5 Ohm
Product Or Component Type:
extended I/O card
Warranty:
18 months
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
Maximum Output Current:
0.2 A, assignable logic
Discrete Input Frequency:
0...30 kHz frequency control
Discrete Output Voltage:
24 V DC <= 30 V) assignable logic
Analogue Output Number:
2
Discrete Input Type:
RP) frequency control 4-6 ms || LI11...LI14) programmable level 1 PLC 3.5 kOhm 4-6 ms
Discrete Input Logic:
negative LI11...LI14), >= 16 V, <= 10 V || positive LI11...LI14), <= 5 V, >= 11 V || positive RP), < 1.2 V, >= 3.5 V
Discrete Output Number:
5
China Rohs Regulation:
X
Discrete Output Type:
LO3, LO4) assignable logic 4-6 ms level 1 PLC || R4A, R4B, R4C) configurable relay logic
Analogue Input Number:
2
Mercury Free:
Yes
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Electrical Connection:
terminal, 1.5 mm² / AWG 16, 0.25 N.m
Maximum Switching Current:
configurable relay logic 5 A 250 V AC resistive, cos phi = 1 || configurable relay logic 5 A 30 V DC resistive, cos phi = 1 || configurable relay logic 1.5 A 250 V AC inductive, cos phi = 0.4 7 ms || configurable relay logic 1.5 A 30 V DC inductive,
Analogue Output Type:
AO2 software-configurable current 0...20 mA 500 Ohm 4-6 ms 10 bits || AO2 software-configurable voltage +/- 10 V DC 470 Ohm 4-6 ms 10 bits || AO3 software-configurable current 0...20 mA 500 Ohm 4-6 ms 10 bits || AO3 software-configurable voltage +/-
Rohs Exemption Information:
Yes
Range Compatibility:
Altivar 61Q || Altivar Lift || Altivar 71Q || Altivar 71 || Altivar 61
Environmental Disclosure:
ENVPEP2010015EN
Discrete Output Logic:
LO3, LO4) negative || LO3, LO4) positive
Discrete Input Number:
6
Analogue Input Type:
AI3-/Al3+ differential current programmable 0...20 mA 250 Ohm 4-6 ms 11 bits + sign || AI4 software-configurable current 0...20 mA 250 Ohm 4-6 ms 11 bits || AI4 software-configurable voltage 0...10 V DC, 24 V max 30000 Ohm 4-6 ms 11 bits
Supply:
internal supply for reference potentiometer, 10.5 V DC 10-11 V) , <0.01 A 1-10 kOhm overload and short-circuit protection || internal supply, 24 V DC 21-27 V) , <0.2 A overload and short-circuit protection
Circularity Profile:
N/A
Sustainable Offer Status:
Green Premium product
Minimum Switching Current:
3 mA 24 V DC configurable relay logic
Pvc Free:
Yes
