Schneider Electric XB4BW31B5 Illuminated Pushbutton

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric XB4BW31B5 Illuminated Pushbutton

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB4BW31B5

UPC:

3389110892031

MPN:

Condition:

New

Ik Degree Of Protection:

IK06 IEC 50102

Light Source:

universal LED

Depth:

57 mm

Device Presentation:

complete product

Width:

30 mm

Ambient Air Temperature For Storage:

-40-70 °C

Shape Of Screw Head:

cross Philips no 1 || cross pozidriv No 1 || slotted flat Ø 4 mm || slotted flat Ø 5.5 mm

Mounting Diameter:

22 mm

Head Type:

standard

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 || IP69 || IP69K

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Environmental Disclosure:

ENVPEP1808008EN

Terminals Description Iso N°1:

(13-14)NO || (21-22)NC

Contacts Material:

silver alloy (Ag/Ni)

Ambient Air Temperature For Operation:

-40-70 °C

Signalling Type:

steady

China Rohs Regulation:

X

Mercury Free:

Yes

Standards:

IEC 60947-5-5 || CSA C22.2 No 14 || IEC 60947-5-4 || IEC 60947-5-1 || JIS C8201-5-1 || UL 508 || IEC 60947-1 || JIS C8201-1

Range Of Product:

Harmony XB4

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Operating Travel:

1.5 mm NC changing electrical state) || 2.6 mm NO changing electrical state) || 4.3 mm total travel)

Protective Treatment:

TH

Service Life:

100000 h at rated voltage and 25 °C

Vibration Resistance:

5 gn 2-500 Hz)IEC 60068-2-6

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

[Ie] Rated Operational Current:

3 A 240 V, AC-15, A600 IEC 60947-5-1 || 6 A 120 V, AC-15, A600 IEC 60947-5-1 || 0.1 A 600 V, DC-13, Q600 IEC 60947-5-1 || 0.27 A 250 V, DC-13, Q600 IEC 60947-5-1 || 0.55 A 125 V, DC-13, Q600 IEC 60947-5-1 || 1.2 A 600 V, AC-15, A600 IEC 60947-5-1

Resistance To Fast Transients:

2 kV IEC 61000-4-4

[Ui] Rated Insulation Voltage:

600 V 3)IEC 60947-1

Net Weight:

0.097 kg

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

[Uimp] Rated Impulse Withstand Voltage:

6 kV IEC 60947-1

Sustainable Offer Status:

Green Premium product

Product Certifications:

DNV || CSA || UL Listed || LROS (Lloyds register of shipping) || GL || BV

Tightening Torque:

0.8-1.2 N.m IEC 60947-1

Supply Voltage Limits:

19.2-30 V DC || 21.6-26.4 V AC

Electrical Durability:

1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 4 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13,

Connections - Terminals:

screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1

Circularity Profile:

ENVEOLI1808008EN

Electrical Shock Protection Class:

class I IEC 60536

Mechanical Durability:

10000000 cycles

Electrical Reliability:

λ < 10exp(-6) 5 V 1 mA in clean environment IEC 60947-5-4 || λ < 10exp(-8) 17 V 5 mA in clean environment IEC 60947-5-4

Operator Additional Information:

with plain lens

Bezel Material:

chromium plated metal

Short-Circuit Protection:

10 A cartridge fuse gG IEC 60947-5-1

Product Or Component Type:

illuminated push-button

[Ith] Conventional Free Air Thermal Current:

10 A IEC 60947-5-1

Contacts Type And Composition:

1 NO + 1 NC

Shape Of Signaling Unit Head:

round

Rohs Exemption Information:

Yes

Operator Profile:

white flush

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Fixing Collar Material:

zamak

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Contacts Usage:

standard contacts

Operating Force:

3.5 N NC changing electrical state || 3.8 N

Contact Operation:

slow-break

Height:

47 mm

Warranty:

18 months

Device Short Name:

XB4

Positive Opening:

with IEC 60947-5-1 appendix K

Bulb Base:

integral LED

[Us] Rated Supply Voltage:

24 V AC/DC 50/60 Hz

Surge Withstand:

1 kV IEC 61000-4-5

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Resistance To Electromagnetic Fields:

10 V/m IEC 61000-4-3

Resistance To Electrostatic Discharge:

6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2

Electromagnetic Emission:

class B IEC 55011

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Current Consumption:

18 mA

Type Of Operator:

spring return

Sale Per Indivisible Quantity:

1
