Schneider Electric XB5AW23G5 Plastic Push-To-Test Pilot Light 110 120

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric XB5AW23G5 Plastic Push-To-Test Pilot Light 110 120

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB5AW23G5

UPC:

3606489420758

MPN:

Condition:

New

Connections - Terminals:

screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1

Embedding Depth:

46 mm

Surge Withstand:

1 kV

Device Short Name:

XB5

Standards:

IEC 60947-1 || JIS C8201-5-1 || UL 508 || CSA C22.2 No 14 || GB 14048.5 || IEC 60947-5-1 || IEC 60947-5-4 || JIS C8201-1

Signalling Type:

steady

Depth:

55 mm

Bezel Material:

plastic

[Us] Rated Supply Voltage:

110...120 V AC 50/60 Hz

Range Of Product:

Harmony XB5

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Shape Of Signaling Unit Head:

round

Tightening Torque:

0.8-1.2 N.m

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 || IP69 || IP69K

[Ui] Rated Insulation Voltage:

600 V 3)IEC 60947-1

Light Source Colour:

green

Current Consumption:

14 mA

[Uimp] Rated Impulse Withstand Voltage:

6 kV IEC 60947-1

Ambient Air Temperature For Storage:

-40-70 °C

Mounting Diameter:

22 mm

Light Source:

universal LED

Protective Treatment:

TH

Product Certifications:

CSA || LROS (Lloyds register of shipping) || DNV || BV || GL || UL Listed

Overvoltage Category:

class II IEC 60536

Electrical Shock Protection Class:

class II IEC 60536

Product Or Component Type:

push-to-test pilot light

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Sale Per Indivisible Quantity:

1

Height:

42 mm

Ik Degree Of Protection:

IK05 IEC 50102

Cap/Operator Or Lens Colour:

green

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Vibration Resistance:

5 gn 12-500 Hz)IEC 60068-2-6

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Net Weight:

0.047 kg

Eu Rohs Directive:

Under investigation

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Fixing Collar Material:

plastic

Width:

30 mm

Service Life:

1.5 year(s)

Ambient Air Temperature For Operation:

-40-70 °C

Datasheet:

View
