Schneider Electric XB5EVG8 Monolithic Led Pilot Light, Yellow, 110V

(No reviews yet) Write a Review

Write a Review

Schneider Electric

Schneider Electric XB5EVG8 Monolithic Led Pilot Light, Yellow, 110V

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB5EVG8

UPC:

3389119041577

MPN:

Condition:

New

Sustainable Offer Status:

Green Premium product

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Standards:

JIS C8201-5-1 || IEC 60947-5-4 || IEC 60947-1 || CSA C22.2 No 14 || IEC 60947-5-1 || JIS C8201-1

Device Short Name:

XB5

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Mounting Diameter:

22 mm

Current Consumption:

14 mA

Product Or Component Type:

pilot light

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 IEC 60529 || IP69 IEC 60529 || IP69K ISO 20653

Range Of Product:

Harmony XB5

Circularity Profile:

ENVEOLI1710010EN

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Supply Voltage Limits:

100-132 V AC

Cap/Operator Or Lens Colour:

yellow

Mercury Free:

Yes

[Ui] Rated Insulation Voltage:

250 V 3)IEC 60947-1

China Rohs Regulation:

X

Protective Treatment:

TH

Resistance To Fast Transients:

2 kV IEC 61000-4-4

Rohs Exemption Information:

Yes

Electromagnetic Emission:

class B IEC 55011

Ik Degree Of Protection:

IK05 IEC 50102

[Us] Rated Supply Voltage:

110...120 V AC 50/60 Hz

Width:

29 mm

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Signalling Type:

steady

Sale Per Indivisible Quantity:

1

[Uimp] Rated Impulse Withstand Voltage:

4 kV IEC 60947-1

Vibration Resistance:

5 gn 12-500 Hz)IEC 60068-2-6

Net Weight:

0.038 kg

Bezel Material:

dark grey plastic

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Resistance To Electromagnetic Fields:

10 V/m IEC 61000-4-3

Connections - Terminals:

screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60947-1 || screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60947-1

Terminals Description Iso N°1:

(X1-X2)PL

Operator Additional Information:

with plain lens

Environmental Disclosure:

ENVPEP1710010EN

Service Life:

100000 h at rated voltage and 25 °C

Compatibility Code:

XB5

Shape Of Signaling Unit Head:

round

Warranty:

18 months

Ambient Air Temperature For Operation:

-25-70 °C

Overvoltage Category:

class II IEC 60536

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Electromagnetic Compatibility:

electrostatic discharge - test level: 6 kV (on contact (on metal parts)) conforming to IEC 61000-4-2 || electrostatic discharge - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2 || electromagnetic emission class B con

Depth:

54 mm

Light Source:

universal LED

Bulb Base:

integral LED

Light Source Colour:

yellow

Head Type:

standard

Resistance To Electrostatic Discharge:

6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2

Ambient Air Temperature For Storage:

-40-70 °C

Surge Withstand:

1 kV IEC 61000-4-5

Product Certifications:

CSA || UL Listed

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Height:

29 mm

Device Presentation:

monolithic product

Shock Resistance:

50 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 30 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Fixing Collar Material:

plastic
