Schneider Electric XB7EV04BP3 Round Pilot Light Diam 22 Ip 65 Red Inte

(No reviews yet) Write a Review

Write a Review

Schneider Electric XB7EV04BP3 Round Pilot Light Diam 22 Ip 65 Red Inte

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

XB7EV04BP3

UPC:

3.38911E+12

MPN:

Condition:

New

[Uimp] Rated Impulse Withstand Voltage:

6 kV EN/IEC 60947-1

Environmental Disclosure:

ENVPEP1805012EN

Mercury Free:

Yes

Ambient Air Temperature For Operation:

-25-70 °C

Product Or Component Type:

pilot light

Device Presentation:

monolithic product

Circularity Profile:

ENVEOLI1805012EN

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Sale Per Indivisible Quantity:

10

Supply Voltage Limits:

19.2-30 V DC || 21.6-26.4 V AC

Connections - Terminals:

Faston connectors 1 x 6.35 mm EN/IEC 60947-1 || Faston connectors 2 x 2.8 mm EN/IEC 60947-1

Current Consumption:

20...27 mA

Device Mounting:

fixing hole 22.5 mm 22.3 +0.4/0 EN/IEC 60947-5-1

Signalling Type:

steady

Ip Degree Of Protection:

IP20 IEC 60529 rear face) || IP65 IEC 60529 front face)

[Ui] Rated Insulation Voltage:

250 V 3)EN/IEC 60947-1

[Us] Rated Supply Voltage:

24 V AC/DC 50/60 Hz

Protective Treatment:

TH

Depth:

54 mm

Warranty:

18 months

Shape Of Signaling Unit Head:

round

Vibration Resistance:

5 gn 2-500 Hz)IEC 60068-2-6

Shock Resistance:

50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Sustainable Offer Status:

Green Premium product

Toxic Heavy Metal Free:

Yes

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Ambient Air Temperature For Storage:

-40-70 °C

Fixing Center:

>= 30 x 40 mm support panel) metal 1-6 mm || >= 30 x 40 mm support panel) plastic 2-6 mm

Reach Free Of Svhc:

Yes

Width:

29 mm

Service Life:

70000 h at rated voltage and 25 °C

Range Of Product:

Harmony XB7

Rohs Exemption Information:

Yes

Mounting Diameter:

22 mm

Light Source:

LED

China Rohs Regulation:

X

Electromagnetic Compatibility:

disturbing field emission class B conforming to EN 55011

Height:

29 mm

Terminals Description Iso N°1:

(X1-X2)PL

Device Short Name:

XB7

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Operator Additional Information:

with plain lens

Net Weight:

0.02 kg

Standards:

JIS C8201-5-1 || EN/IEC 60947-1 || CSA C22.2 No 14 || EN/IEC 60947-5-1 || UL 508 || JIS C8201-1

Bulb Base:

integral LED

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Cap/Operator Or Lens Colour:

red

Overvoltage Category:

class II IEC 60536

Fixing Mode:

fixing nut beneath head 2-2.4 N.m

Nema Degree Of Protection:

NEMA 4 UL 50 E || NEMA 12 UL 50 E

Datasheet:

View
