Schneider Electric ZB4BV5D4 400 V Led Transfo Light B
Schneider Electric
$150.00
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB4BV5D4 400 V Led Transfo Light B
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Complete body/light block assembly, Harmony XB4, red light, with body/fixing collar, BA9s LED bulb, 400V AC
- Device Short Name:
- ZB4
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Protective Treatment:
- TH
- Ip Degree Of Protection:
- IP20
- Signalling Type:
- steady
- Sale Per Indivisible Quantity:
- 1
- Bulb Base:
- BA 9s
- Cad Overall Depth:
- 60 mm
- Electrical Shock Protection Class:
- class I IEC 60536
- Standards:
- CSA C22.2 No 14 || IEC 60947-5-4 || IEC 60947-5-5 || IEC 60947-5-1 || IEC 60947-1 || UL 508 || JIS C8201-5-1 || JIS C8201-1
- Environmental Disclosure:
- ENVPEP1808008EN
- Circularity Profile:
- ENVEOLI1808008EN
- Light Source:
- LED
- Shape Of Screw Head:
- cross Philips no 1
- Cad Overall Width:
- 30 mm
- Cad Overall Height:
- 47 mm
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- China Rohs Regulation:
- X
- Range Of Product:
- Harmony XB4
- Light Source Colour:
- red
- Net Weight:
- 0.134 kg
- Fixing Collar Material:
- zamak
- [Ui] Rated Insulation Voltage:
- 600 V 3)IEC 60947-1
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Ambient Air Temperature For Operation:
- -40-70 °C
- Mercury Free:
- Yes
- Product Certifications:
- CSA || BV || GL || LROS (Lloyds register of shipping) || DNV || UL Listed
- [Us] Rated Supply Voltage:
- 400 V AC 50/60 Hz
- Sustainable Offer Status:
- Green Premium product
- Light Block Supply:
- via integral transformer 1.2 VA 6 V
- Product Or Component Type:
- complete body/light block assembly
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Tightening Torque:
- 0.8-1.2 N.m IEC 60947-1
- Electrical Composition Code:
- P4
- Ambient Air Temperature For Storage:
- -40-70 °C
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Connections - Terminals:
- screw clamp terminals, <= 2 x 1.5 mm² with cable end
- [Uimp] Rated Impulse Withstand Voltage:
- 6 kV IEC 60947-1
- Rohs Exemption Information:
- Yes
- Mounting Of Block:
- front mounting
- Warranty:
- 18 months
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27
- Terminals Description Iso N°1:
- (X1-X2)PL
- Catalog:
- View
- Datasheet:
- View
