Schneider Electric ZB5APA2C0 Pushbutton Operator Head
Schneider Electric
$13.59
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This clear silicone booted button head provides a simple solution to comply with hygiene requirement in food, beverage industries as well as healthcare and pharmaceuticals. It is easily installed and replaced on compatible complete push-button units and contact blocks via snap-fit assembly. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments.
- Cad Overall Width:
- 30 mm
- Cad Overall Height:
- 30 mm
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Ambient Air Temperature For Storage:
- -40-70 °C
- Product Or Component Type:
- head for non-illuminated push-button
- Device Short Name:
- ZB5
- Ik Degree Of Protection:
- IK03 IEC 50102
- Protective Treatment:
- TH
- Sale Per Indivisible Quantity:
- 1
- Bezel Material:
- plastic colour plated grey
- Mercury Free:
- Yes
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Product Certifications:
- LROS (Lloyds register of shipping) || UL Listed || DNV || GL || CSA || BV
- Rohs Exemption Information:
- Yes
- Head Type:
- standard
- Operator Additional Information:
- clear boot
- Range Of Product:
- Harmony XB5
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- China Rohs Regulation:
- X
- Standards:
- EN/IEC 60947-1 || EN/IEC 60947-5-1 || EN/IEC 60947-5-4 || UL 508 || JIS C8201-5-1 || CSA C22.2 No 14 || JIS C8201-1
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Mounting Diameter:
- 22 mm
- Type Of Operator:
- spring return
- Shape Of Signaling Unit Head:
- round
- Operator Profile:
- black flush, unmarked
- Cad Overall Depth:
- 37 mm
- Overvoltage Category:
- class II IEC 60536
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Mechanical Durability:
- 10000000 cycles
- Product Compatibility:
- not compatible with legend holder
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 IEC 60529
- Ambient Air Temperature For Operation:
- -40-70 °C
