Schneider Electric ZB5AZ1023 Body + Nc Contact
This Harmony ZB5AZ1023 is a single contact block with body/fixing collar, 1 NC faston connector. It is part of the range Harmony XB5 diameter 22mm modular plastic push buttons, switches, and pilot lights.
- Contacts Type And Composition:
- 1 NC
- Circularity Profile:
- ENVEOLI1710010EN
- Device Short Name:
- ZB5
- [Ui] Rated Insulation Voltage:
- 250 V 3)EN 60947-1
- Head Type:
- standard
- Contacts Material:
- silver alloy (Ag/Ni)
- Ambient Air Temperature For Operation:
- -40-70 °C
- Warranty:
- 18 months
- China Rohs Regulation:
- X
- Contact Block Type:
- single
- Cad Overall Depth:
- 32 mm
- Fixing Collar Material:
- plastic
- Electrical Reliability:
- λ < 10exp(-6) 5 V, 1 mA in clean environment EN/IEC 60947-5-4 || λ < 10exp(-8) 17 V, 5 mA in clean environment EN/IEC 60947-5-4
- Standards:
- CSA C22.2 No 14 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || EN/IEC 60947-5-1 || JIS C8201-5-1 || UL 508 || JIS C8201-1
- Cad Overall Height:
- 42 mm
- Net Weight:
- 0.021 kg
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Toxic Heavy Metal Free:
- Yes
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Product Or Component Type:
- complete body/contact assembly
- Ip Degree Of Protection:
- IP20 IEC 60529
- Sustainable Offer Status:
- Green Premium product
- Cad Overall Width:
- 30 mm
- Ambient Air Temperature For Storage:
- -40-70 °C
- Rohs Exemption Information:
- Yes
- Contacts Usage:
- standard contacts
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Environmental Disclosure:
- ENVPEP1710010EN
- Operating Travel:
- 1.5 mm NC changing electrical state) || 4.3 mm total travel)
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Connections - Terminals:
- Faston connector 1 x 6.35 mm || Faston connector 2 x 2.8 mm
- Reach Free Of Svhc:
- Yes
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Protective Treatment:
- TH
- Mercury Free:
- Yes
- Device Composition:
- body || fixing collar
- Operating Force:
- 2 N NC changing electrical state
- Sale Per Indivisible Quantity:
- 1
- Positive Opening:
- with EN/IEC 60947-5-1 appendix K
- Range Of Product:
- Harmony XB5
- Terminals Description Iso N°1:
- (11-12)NC
- Contact Operation:
- slow-break
- Mechanical Durability:
- 10000000 cycles
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Product Certifications:
- DNV || LROS (Lloyds register of shipping) || GL || UL || BV || CSA
