Schneider Electric ZB5FH083C0 Flmnt Illum. Push Push But. Yellow- Cap

Schneider Electric ZB5FH083C0 Flmnt Illum. Push Push But. Yellow- Cap

Schneider Electric
SKU:
ZB5FH083C0
|
UPC:
3606489773083
Availability:
Contact us to confirm availability and lead times.
$34.32
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This 30.5mm head for illuminated push-button provides an ergonomic interface for controlling your machine. It is easily installed and replaced on compatible complete push-button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration resistant, impact resistant, high pressure washer resistant and dust resistant thanks to its IP67, IP66 protection, making it ideal for operation in harsh environments.
Additional Information
Important Message:
A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks
Ambient Air Temperature For Operation:
-40-70 °C
Resistance To High Pressure Washer:
7000000 Pa 55 °C 0.1 m
Mercury Free:
Yes
Rohs Exemption Information:
Yes
Product Or Component Type:
head for illuminated push-button
Shape Of Signaling Unit Head:
round
Protective Treatment:
TH
Mounting Diameter:
30.5 mm
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Net Weight:
0.031 kg
Ik Degree Of Protection:
IK03 IEC 50102
Range Of Product:
Harmony XB5
Mechanical Durability:
500000 cycles
China Rohs Regulation:
X
Device Short Name:
ZB5F
Operator Profile:
yellow flush, unmarked
Product Compatibility:
universal LED
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Type Of Operator:
push-push
Vibration Resistance:
5 gn 10-500 Hz)IEC 60068-2-6 || 2 mm peak to peak 2-10 Hz)IEC 60068-2-6
Ambient Air Temperature For Storage:
-40-70 °C
Ip Degree Of Protection:
IP66 IEC 60529 || IP67 IEC 60529
Device Presentation:
basic element
Sale Per Indivisible Quantity:
1
Electrical Composition Code:
C11 3 single front mounting || C15 1 single front mounting || SF1 3 single front mounting || C9 3 single front mounting
Cad Overall Width:
37 mm
Bezel Material:
plastic colour plated grey
Toxic Heavy Metal Free:
Yes
Head Type:
built-in-flush
Warranty:
18 months
California Proposition 65:
WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Cad Overall Depth:
32 mm
Overvoltage Category:
class II IEC 60536
Cad Overall Height:
37 mm
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 || 25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27
Product Certifications:
UL Listed || CSA
Reach Free Of Svhc:
Yes
Standards:
UL 508 || EN/IEC 60947-5-4 || EN/IEC 60947-1 || JIS C8201-5-1 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || JIS C8201-1
