Schneider Electric ZB5SZ3 Dia 22 Hole Cap

Schneider Electric ZB5SZ3 Dia 22 Hole Cap

Schneider Electric
SKU:
ZB5SZ3
|
UPC:
3389110099522
Availability:
Contact us to confirm availability and lead times.
$11.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This Harmony plastic blanking plug is compatible with Harmony XB4, XB5 and XB7 pushbuttons with flush push. This plastic blanking plugis designed as an option to fit with your pushbutton units when no function is needed for machine to operate. It is compatible with standard 22mm XB4, XB5 and XB7 control and signaling units. It has a plastic bezel, this makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation. It is designed to fit with a standard 22mm control and signaling units, ensuring compatibility when installing in pre-existing machinery.
Additional Information
Head Type:
standard
Accessory / Separate Part Type:
blanking plug
Ik Degree Of Protection:
IK03 IEC 50102
Main Colour Tint:
dark grey
Reach Free Of Svhc:
Yes
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Warranty:
18 months
Nema Degree Of Protection:
NEMA 13 || NEMA 4X
Standards:
JIS C8201-5-1 || EN/IEC 60947-1 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || EN/IEC 60947-5-4 || UL 508 || JIS C8201-1
Accessory / Separate Part Destination:
Ø 22 mm cut-outs for circular heads
Station Name:
XALD 2...5 cut-outs || XALK 2...5 cut-outs
Operator Profile:
flush
Bezel Material:
dark grey plastic
California Proposition 65:
WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Accessory / Separate Part Category:
installation accessories
Device Composition:
nut || blanking plug
Environmental Disclosure:
ENVPEP081202-EN
Sale Per Indivisible Quantity:
10
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Rohs Exemption Information:
Yes
Toxic Heavy Metal Free:
Yes
China Rohs Regulation:
X
Product Or Component Type:
blanking plug
Ip Degree Of Protection:
IP66 IEC 60529 || IP67 || IP69 || IP69K
Material:
plastic
Range Of Product:
Harmony XB5 || Harmony XB4
Mercury Free:
Yes
Shape Of Signaling Unit Head:
round
Net Weight:
0.009 kg
